35
• Remove the rack by slightly bending the lowest
metal rod to loosen it from the mounting screw
and pulling it towards the oven center.
• Lift the rack upwards out of the upper mounting
holes.
• Replace the racks after cleaning and drying them
thoroughly.
Cleaning the glass panes
If necessary, clean the inside of the glass panes.
• Open the oven door.
• Remove the support bar by loosening the screws
on the side of the bar.
• Carefully remove the glass panes forward from
the holder.
• Replace the glass panes and fasten the retaining
strip after you have cleaned and thoroughly dried
the glass.
Changing the bulb
WARNING:
• Make sure that the appliance is turned off from
the power supply (fuse).
• Allow the lamp to cool down before replacing the
bulb. Danger of burns!
NOTE:
Use the correct bulb, heat resistant up to 300°C:
G9 Halogen - 1 x 25 W - 220-240 V~
• Unscrew the lamp cover and
clean it with a dry cloth.
• Change the bulb.
• Screw the lamp cover on tightly
and check for proper operation.
Troubleshooting
Before you contact an authorized specialist
Problem
Possible cause / Action
Oven does
not work
Check the power supply.
Oven lamp
does not
work
Bulb is defective, was inserted in-
correctly, is not securely seated in
the socket, see
“Changing the
bulb”.
Strong
smoke deve-
lopment
Grease residues in the oven
chamber, switch off the oven, al-
low to cool before cleaning.
NOTE:
If a problem persists after following the steps above,
contact your distributor or an authorized technician.
Technical data
Electrical connection…………………………...………..
Connection voltage: ………..380-420V 3N~ 50/60 Hz
Rated power: ………..……………..…..…........8400 W
Rated current: ………………......………....…..3 x 16 A
Protection class: ………………………...………I / IP20
Dimension / weight……...……..………………………..
Worktop cutout (WxD): ……….…….....56.0 x 49.0 cm
Hob net weight: …………….…………..……...…7.0 kg
Cabinet cutout (HxWxD): ..60.0 x 56.0 x min. 55.0 cm
Oven net weight: …………………………..……30.0 kg
Available accessories……………………………………
Telescopic runner set: …………..…Art. no. 8 979 090
………………………………………………
(not supplied)
