BS6072CB_IM_10.2024 23.10.24
9
- Brush Nozzle:
Gently removes dirt from slits in upholstery and mat-
tresses. Also suitable for picking up dust on sensitive
surfaces such as furniture or curtains.
Telescopic Suction Tube
You can adjust the length of the telescopic suction tube
individually:
1. Attach the telescopic suction tube to the connection on
the appliance by turning it slightly.
2. Release the lock by pushing the button in the direction of
the arrow and holding it.
3. Pull one tube out of the other to the desired length.
4. Release the button to lock the connection.
5. Fit the floor nozzle or accessories.
Electrical Connection
• Before inserting the mains plug into the socket, check
that the mains voltage is correct. You will find the details
of the appliance on the type plate.
• Only connect the appliance to an approved socket.
Switching the Appliance On / Off
• The appliance is switched off when the switch is in the
O position.
• Set the switch to position I to switch on the appliance.
Mounting the Wall Bracket
CAUTION:
Make sure beforehand that there are no hidden cables in
the wall that could damage you!
1. Measure the height for the wall bracket. Hold the
appliance against the wall when it is mounted with the
telescopic suction tube and floor nozzle.
2. Hold the wall bracket against the wall so that the opening
points upwards. Mark 3 holes.
3. Drill the holes and place the plugs in the wall.
4. Insert the screws through the holes in the wall bracket.
Screw the screws into the plugs.
5. Hand-tighten the screws with a suitable screwdriver.
Operation
1. Unwind the mains cable completely.
2. Insert the mains plug into a properly installed protective
contact socket.
3. Switch the appliance on with the on / off switch.
4. Tilt the lever to “brushes extended” or “brushes retracted”
depending on the floor covering.
5. Now vacuum with even speed. It is not necessary to
press down.
- Be aware of the limited range due to the length of the
cable!
End Operation
1. Switch off the appliance. Then pull the mains plug out of
the socket.
2. Let the appliance cool down completely.
3. If you have previously mounted the wall bracket, hang
the appliance in it.
4. Loosely roll up the mains cable. You can use the hook-
and-loop tape on the mains cable to secure the cable.
Maintenance
Pull the mains plug out of the socket before cleaning or
maintaining the appliance.
Emptying the Dust Container
1. Pull the mains plug out of the socket.
2. If necessary, detach the suction tube or nozzle attach-
ment from the appliance.
3. Hold the appliance with the base plate of the dust con-
tainer over a dustbin.
4. Empty the contents of the dust container. To do this,
press the button (8) to open the base plate.
5. Close the base plate again. The lock on the dust con-
tainer must engage.
The Filter System
Your appliance has 3 filters. The conventional dust bag sys-
tem has been replaced by a transparent dust container. In it,
coarse dirt and the smallest suspended particles are whirled
out of the “suction air” by the high flow speed.
There is no need to buy dust bags.
The filters must be cleaned regularly.
CAUTION:
• Never wash the filters in the washing machine.
• Do not use a hair dryer to dry them.
• Only put the appliance back into operation when all
filters are completely dry and correctly fitted.
The Filter Unit
The filter unit is composed of:
• HEPA filter
• Coarse filter
To clean the filter unit, proceed as follows:
1. Empty the dust container as previously described.
