SYSTEM RESET:

Soft reboot to save the changes have been made and make the changes activated

EXIT: Push the joystick to the right to exit this level menu.

FUNCTION SETTING Menu

The FUNCTION SETTING menu is used to set the items related to the camera functionalities.

Note: The number of available presets may be limited by the head-ins, controllers, and DVRs that are connected to your dome

system.

PRESETS SETUP:

Preset is to store the PTZ information (such as: Pan and Tilt positions, focal

length etc.) under the specific condition, and call the camera PTZ quickly to shoot

to the specified location that you want the camera to move to.

Note: Presets not only save desired image positions, various picture settings such

as brightness, exposure values and other variables are also saved and stored.

Note: Pan and Tilt are not available on the FEX model.

The menu is used to manage the presets. Total of 220 presets can be managed.

PRESETS NUMBER:

The current preset number that you are managing.

SET NEW PRESET:

To set up (or overwrite) the preset of the preset shown under PRESET

NUMBER

1. Enter this setting menu, you will see “call preset 1 to end” flashing on

the screen.

2. Adjust the camera to the position that you want the preset to be

3. Call the preset 1 using the keyboard to save the preset as the current

position

DELETE PRESET:

With this option selected, push the joystick to the right to delete the preset

shown under PRESET NUMBER preset.

EXIT: Push the joystick to the right to exit this level menu.

There are pre-programmed functionalities of the camera have been setup with presets, means that these

functionalities can be activated or trigged by running certain presets or setting certain presets. For example, run

preset 95 is to turn on the OSD menu displayed on the screen, etc.

In order to use the special functions of the camera, the following presets are predefined for specific functions (You

can find the default predefined preset at Web interface, Setup -> PTZ -> Advanced Settings):

EXPOSURE

WHITE BALANCE


LENS PARAMETERS

SYSTEM SETUP

>FUNCTION SETTING

EXIT

PRESETS SETUP

TOUR SETUP

PATTERN SETUP

IDLE TIMER ：003

IDLE ACTION ：OFF

EXIT

>PRESET NUMBER: 001

PRESET MEMORY: ON

>SET NEW PRESET

DELETE PRESET

EXIT

PRESET NUMBER: 001

PRESET MEMORY: ON

SET NEW PRESET

>DELETE PRESET

EXIT

CALL PRESET 1 TO END
