Furthermore, there are speed-setting sliders that permit the user to alter the speed of the camera’s
movements, including pan, tilt, focus, and zoom. This allows the user to customize the camera’s operations to
suit their needs.
Within the PTZ Setting drop-down menu, the user will discover the following options:
Auto-Scanning: The camera image pans automatically from left to right or right to left at a speed defined1.
by the user (Speeds 1-8).
Preset: The user can set and recall up to 64 camera presets (The camera supports saving a total of 2552.
presets). These presets can be recalled through the web interface, IR Remote, or PTZ Controller.
Tracking: The camera will record a series of presets that are recalled in a specified order.3.
Scanning: The camera image pans from left to right or right to left between up to 12 points defined by4.
the user at a speed also defined by the user (Speeds 1-8).
Power On Action: Users can define a set of actions that a camera performs (preset recall, scan, trace, or5.
cruise) once powered on.
Cruise: The camera will record a series of movements that an operator makes, which can then be6.
recalled whenever a user prefers.
Creating and Recalling Presets
To save presets, the user should adhere to the following steps:
Utilize the PTZ controls of the web interface, IR controller, or a PTZ controller to adjust the camera to the1.
position(s) they wish to save as a preset.
After positioning the camera, click on the ‘Create’ button. Subsequently, select the preset number under2.
which they want to save this setting. Label the preset in the ‘Name’ field and click ‘Save’.
To recall a preset, select the preset number on the Web Interface and click the “Go” button.3.
A saved preset can also be deleted by selecting it and clicking on the Delete button.4.
Adjusting OSD Menu Settings from the Web Interface
The OSD Menu settings can be accessed and adjusted from the Web Interface. On the “Live View” page,
locate and click the “Menu” icon situated at the bottom right of the live view image to display the OSD menu.
The user can navigate through these settings using the arrows under “Pan/Tilt Control”. The middle button is
used to select, and the right arrow button is used to modify the setting. To exit this menu, simply click on the
“Menu” icon again. The settings available in this menu encompass:
Adjust Exposure, White Balance, Picture (Noise Reduction, E-Flip, ND Filter, IR Filter), Gamma, Lens (Focus,
Stabilization), Pan & Tilt, Genlock, System (Pelco, Visca, IR, Baud Rate, Tally, Audio, Video Format) settings,
and view System Status.
Settings
Device
The Device tab provides key device information and allows the user to modify the PTZ Camera's Name. It also
displays the Model Number and firmware versions. These details are essential for firmware updates, support,
and troubleshooting.
