and connect the other end to either a network switch or directly to a computer.
Access the Web Interface – On a computer, open an HTML5-enabled web browser and enter the2.
camera’s IP address. By default, the camera is set to DHCP, so the IP address is assigned by the
network.
Enable and Configure Streaming – In the web interface, navigate to the "AV Setup" menu on the left side.3.
From here, enable and adjust the IP stream settings as needed.
VISCA over IP
Bolin PTZ cameras support VISCA over IP communication, allowing for remote control and integration with
compatible systems over a network. To establish a connection, ensure that your control system or software is
configured to communicate with the camera using port 52381.
Key Requirements:
Network Configuration: The camera and control device must be on the same subnet or properly routed for
network communication.
Port Settings: Ensure that port 52381 is open and accessible for VISCA over IP commands.
Control Protocol: Standard VISCA over IP commands can be used for functions such as pan, tilt, zoom,
focus, and preset recalls.
NOTE: The VISCA over IP port of the controller MUST be set to 52381 to communicate with
and control the camera.
ONVIF Protocol
Bolin PTZ cameras support ONVIF 2.4 (Profile S), ensuring compatibility with a wide range of third-party
applications, including PTZ controllers and streaming software. These cameras use the standard ONVIF port
2000 for communication.
ONVIF compliance enables device discovery, video streaming, and PTZ control, making these cameras ideal
for live production, broadcasting, and professional AV workflows.
Integrating with ONVIF-Supported Software:
Ensure the camera is connected to the network and properly configured.1.
Use an ONVIF-compliant application to detect the camera.2.
Enter the camera’s IP address, ONVIF credentials (web login credentials), and port 2000 during setup.3.
Configure video and PTZ settings as needed for the application.4.
ONVIF 2.4 (Profile S)
ONVIF Port: 2000
RS-422 Serial Commands (VISCA)
The camera is equipped with an RS-422 port, which facilitates VISCA control over serial commands. This
RS-422 port is also compatible with RS-485. The camera can be connected via a serial connection to a PTZ
controller or a computer. This allows for the execution of pan, tilt, and zoom operations, as well as the
performance of preset recalls.
CAUTION: When one connects the camera via serial to a Sony PTZ controller, it differs
from the process with a non-Sony PTZ controller. It is crucial to verify the pin settings
for the specific controller in use.
The camera should be powered on, and the OSD menu should be opened or the Web Interface should be1.
logged into using any web browser. Proceed to the system settings and adjust the baud rate to match
