This user guide is suitable for the following Bolin Dante AV™ cameras:
D2-210 H and D2-220H
Camera features
o Dante AV™H supports Unicast or Multicast video streaming over a standard 1Gbps Ethernet.
o Sony 1/2.8 Inch CMOS sensor, Effective pixel number: 2.13 Megapixels.
o Resolution: Up to 1920×1080p60/50/30/25fps.
o Color Space supports YUV(YCbCr) and RGB.
o IP Resolution: Up to 1080P60.
o The D2-210H has a 10X optical and 16X digital zoom and the D2-220H a 20X optical and 16X
digital zoom.
o 3G-SDI video output: D2-220H only.
o HDMI1.4 -Type A and USB 2.0 - Type C.
o On screen display (OSD), WDR On/Off, Day/Night mode On/Off, Contrast, Color Hue, Color Matrix,
Gamma (0 to 4) and High Sensitivity.
o Auto and Manual Exposure, Shutter / Day/NIght / Brightness priority.
o Focus Zone: Face Priority, All Area, Upper Area, Central Area and Lower Area
o AI Face Detection Focus and Exposure.
o 2D and 3D Noise Reduction (1-255).
o Four PTZ Trace Memory supported via IP interface, Noise Reduction and Tally Light.
o Video Output: HDMI 1.4 and Dante AV-H™ simultaneously.
o Latency Codec <280ms at 1080p60
o Synchronized Video and Audio.
o Dante AV™ Ecosystem integration with existing Dante-enabled products, Unified control of audio.
and video using Dante Controller.
o ±175 degrees continuous pan, +90 degrees to -30 degrees continuous tilt.
o 255 presets, Speed up to 150°/S, accuracy: 0.05° with 6 presets on remote control.
o Standard mounting and ceiling mounting with E-Flip function.
o Control via RS-422(RJ45 x1) IP controls (RJ45 x1) and IR Remote Control.
o Image parameter setting restore with presets and quick access operation.
o MIC/LINE audio input (D2-210H only) and USB port to 3.5mm audio jack (D2-220H).
o Power: DC 12V, PoE+ (IEEE802.3at).
o Firmware upgrade via USB2.0 or Dante AV™ software.
Software Installation
❖ Required software from Audinate: Download and install Dante Controller from Audinate’s website
on your PC: https://my.audinate.com/support/downloads/dante-controller
❖ Suggested additional software available from Audinate: Dante Studio™ to stream PTZ camera and
Dante AV content by seamlessly integrating your PC and applications such as vMix, Zoom, OBS
etc. https://my.audinate.com/forms/dante-studio-trial-survey
Camera Features & Software
