Important Notes and Tips:

1. Before assembly, read all instructions thoroughly and preview diagrams to help make the

installation easier.

2. Make sure all parts are accounted for and in proper condition before beginning assembly.

See the parts list.

3. Be cautious not to damage the flooring when assembling. Place a protectant down such as a

rubber mat or shipping blanket.

4. Let plastics and weight stacks acclimate to room temperature before you begin assembly.

5. Two people are recommended for the safe assembly of this equipment.

6. Insert all bolts in the same direction when possible. Do not tighten until instructed.

7. Carefully install plastic caps using a rubber mallet.

8. When measuring bolt lengths, only measure the

shank.

9. When the installation is complete, be sure to

regularly check for rust or damage, and

perform preventative maintenance.

Important Notes, Recommended Tools & Cleaners , GT

THE FOLLOWING TOOLS ARE RECOMMENDED FOR EASIER ASSEMBLY:

SOCKET SET WITH 3“ & 6”

EXTENSION for 13mm & 17mm

OPEN & CLOSED WRENCHES

for 13mm & 17mm

ALLEN WRENCHES SET

4mm to 10mm)

PHILLIPS SCREWDRIVERS

#2 w/ Magnetic TIP

TIP ON FRAME ONLY: For extra

protection from fingerprints,

sweat stains or just plain dirt,

apply an automotive grade

cleaner wax if desired. Also

makes future cleaning easier.

THE FOLLOWING IS RECOMMENDED FOR CLEANING:

100% COTTON

CLEANING CLOTHS

(Do Not Use on the Upholstery)

MILD CLEANING

SOLUTION

6

ALLEN WRENCH SET

1/16” thu 3/8" SAE

Recommended Tools

ALLEN WRENCH SET

(Only 7/32 is needed)

TORQUE WRENCH

3/8 DRIVE

SOCKET SET 3/8 DRIVE & 6” EXT

(Only 1/2, 9/16, & 3/4 Sockets

are needed)

OPEN, CLOSED &

ADJUSTABLE WRENCHES

(Only 1/2, 9/16 & 3/4

are needed)

TORQUE WRENCH

3/8 DRIVE

(w/ 5/32, 3/16, 1/4 &

3/8 Hex Bit Socket)

THE FOLLOWING TOOLS ARE RECOMMENDED FOR ASSEMBLY:

RUBBER MALLET &

ALLEN WRENCH SET

(w/ 5/32, 3/16, 1/4 & 3/8

are needed)

ALLEN WRENCH SET

(Only 5/16 & 3mm

are needed)
