Parts List
39
#Description QTY
69
Sensor Rack
1
70
Motor Cover Anchor
2
83
450m/m_Connecting Wire, White
1
98
Retaining Plate
2
99
Power Line Cord
1
100 5 × 20m/m_Tapping Screw 21
101
Ø18 × Ø19 × 41L_Carriage Bolt
2
102
M8 × 1.25 × 12L_Hex Head Bolt
2
103 3/8"-16 × 25L_Hex Head Bolt 4
104 Ø8.5 × 26 × 2.0T_Flat Washer
2
105 M10 × 65L Hex Head Bolt 1
106 M10 × 50LHex Head Bolt 1
107 Ø10 × 1.5T_Split Washer6
108 Ø10 × Ø19 × 1.5T_Flat Washer 8
109
M10 × 8.0T_Nylon Lock Nut
2
110
Ø10 × Ø24 × 2T_Nylon Washer
2
111 3/8"-16 × 1-1/2"_Socket Head Cap Bolt 4
112 3/8" × 2-1/2"_Hex Head Bolt 1
113 3/8"-16 × 2"_Socket Head Cap Bolt
1
114
Ø10 × Ø14 × 14L_Isolation Bushing
5
115
13 × 35 × 5T_Nylon Washer
9
116 Ø3/8" × 35 × 2T_Flat Washer 11
117 3/8'' × 16.5 × 2.0T × 4H_Lock Washer17
118
3/8" × 7T_Nylon Lock Nut
2
119 M8 × 1.25 × 40L_Socket Head Cap Bolt 6
120 Ø8 × 1.5T_Lock Washer22
121 Ø8 × 16 × 1T_Flat Washer 22
122 M8 × 1.25 × 90LSocket Head Cap Bolt 8
123 M8 × 1.25 × 55L_Hex Head Bolt 8
124 M8 × 1.25 × 6.5T_Nut 16
