STEP

Be careful to assemble all components

in the sequence they are presented.

NOTE:

Wrench tighten ALL hardware at the end of each step. Some components may be

pre-assembled. Nylon lock nuts will not fully screw onto bolts, they must be wrench

tighten to fully go on.

3A. AttachLeftArmFrame(G)toUpperLeftUpright(E)using:

2 - (#1) M12x130mm Hex Head Bolt

4 - (#10) M12 Flat Washer

2 - (#15) M12 Nylon Lock Nut

3B. AttachRightArmFrame(H)toUpperRightUpright(F)using:

2 - (#1) M12x130mm Hex Head Bolt

4 - (#10) M12 Flat Washer

2 - (#15) M12 Nylon Lock Nut

3C. AttachArmPads(#24)toArmFrames(G & H)using:

4 - (#7) M8x70mm Hex Head Bolt

4 - (#13) M8 Flat Washer

4 - (#14) M8 Lock Washer

3D. AttachBackPad(#17)toCenterFrame(D)using:

2 - (#7) M8x70mm Hex Head Bolt

2 - (#13) M8 Flat Washer

2 - (#14) M8 Lock Washer
