Part numbers are required when ordering parts.
Parts List
37
PART# DESCRIPTION QTY
32
35 Console Monitor Front Cover 1
36 Console Monitor Back Cover 1
37 Tablet Holder 1
38 Tablet Holder Base 1
40 Transport Wheel 2
42 Stabilizer Foot Pad 8
43 Cushion 2
44 Cable 1
47 Power Switch 1
48 Power Cord 1
49 LED Control Knob 1
50 Adaptor 1
51 Fan 1
52 Speed Sensor 1
54 DC Power Cable 1
56 Phillips Pan Head Self-Tapping Screw, ST4.2x16mm 4
57 Phillips Pan Head Screw, M4x30mm 4
59 Button Head Cap Screw, M5x8mm 37
60 Button Head Cap Screw, M6x8mm 27
61 Flat Washer M6 22
62 Socket Head Cap Screw, M4x20mm 8
66 Button Head Cap Screw, M6x12mm 8
67 Socket Head Cap Screw, M6x16mm 6
68 Spring Washer M6 6
69 Socket Head Cap Screw, M8x10mm 8
72 Socket Head Cap Screw, M8x40mm 2
73 Flat Washer M8 4
74 Nylon Nut M8 4
75 Button Head Cap Screw, M10x45mm 1
76 Flat Washer M10 1
77 Nylon Nut M10 1
78 Socket Head Cap Screw, M8x15mm 2
79 Hex Nut M10 1
80 C Ring Φ20 2
81 Phillips Flat Head Screw, M5 x 30mm 2
ϯϮ
78 Socket Head Cap Screw, M8x15mm 2
79 Hex Nut M10 1
80 C Ring Φ20 2
81 Phillips Flat Head Screw, M5 x 30mm 2
82 Upper Tablet Holder Hook 1
83 Bungee Cord 1
84 EVA Pad (Upper Tablet Holder Hook) 1
85 EVA Pad (Tablet Holder Base) 1
88 Allen Wrench 6mm 1
89 Allen Wrench 4mm 1
90 Foot Pad Adjustment Lever 6
91 Open End Wrench 13-15-17mm 1
92 Roller Protector 2
93 Long Parallel Key 1
94 Short Parallel Key 1
95 Spring Handlebar Lock 6
96 Spring Handlebar Lock Axis 2
97 Handlebar Sleeve 2
99 LED Console 1
100
Nylon Spacer
2
101
Socket Head Cap Screw, M5x37mm
2
102
Socket Head Cap Screw, M5x45mm
1
103
Socket Head Cap Screw, M5x10mm
4
104
Flat Washer 16*6.2*1.5T
1
105
Socket Head Cap Screw, M8x70mm
4
106
Lock Washer M8
4
107
Arc Washer M8
6
108
Support Connection Tube
1
109
Pre-assembled Socket Head Cap Screw, M8x14mm (include Spring Washer
& Flat Washer)
24
110
Adjustment Spacer Φ12*Φ8.2*11
1
111
Flat Washer Φ38*Φ12*3
2
112
Counterbored Washer
2
113
Star Nut (Double Layer) M6*10
2
ø4x 350mm
Handlebar Grip
