HEX100HDVGA-KIT USER MANUAL

www.blustream.co.uk

Surge protection device

recommended

This product contains sensitive electrical

components that may be damaged

by electrical spikes, surges, electric

shock, lightning strikes, etc. Use of surge

protection systems is highly recommended

in order to protect and extend the life of

your equipment.

Safety And

Performance Notice

The transmission distances of HDMI

over UTP cables are measured using TE

CONNECTIVITY 1427071-6

EIA/TIA-568-B termination (T568B) of cables

is recommended for optimal performance.

To minimise interference of the unshielded

twisted pairs in the CAT5e/6 cable do not

run the HDBaseT/Cat5e/6/6a cabling with

or in close parallel proximity to mains

power cables.

Do not substitute or use any other power

supply other than the enclosed unit, or a

Blustream approved replacement.

Do not disassemble either the Transmitter

or Receiver units for any reason. Doing so

will void the manufacturer’s warranty.

Introduction 03

Features 03

Panel Descriptions 04

Terminating HDBaseT

™ CAT Cables 05

Understanding TX/RX Status Lights 05

EDID Control 06

InfraRed Distribution 07

Application Diagram 08

Specifications 09

Package Contents 09

Maintenance 09

Contents

Thank you for purchasing

this product.

For optimum performance and safety,

please read these instructions carefully

before connecting, operating or

adjusting this product. Please keep this

manual for future reference.
