EN / 45
9.5 Cleaning the inside of the oven
(cooking area)
Follow the cleaning steps described in the
"General Cleaning Information" section ac-
cording to the surface types in your oven.
Cleaning the side walls of the oven
The side walls in the cooking area can only
be covered with enamel or catalytic walls. It
varies by model. If there is a catalytic wall,
refer to the “Catalytic surfaces” section for
information.
If your product is a wire shelf model, re-
move the wire shelves before cleaning the
side walls. Then complete the cleaning as
described in the "General Cleaning Informa-
tion" section according to the side wall sur-
face type.
To remove the side wire shelves:
1. Remove the front of the wire shelf by
pulling it on the side wall in the opposite
direction.
2. Pull the wire shelf towards you to re-
move it completely.
3. To reattach the shelves, the procedures
applied when removing them must be
repeated from the end to the beginning,
respectively.
9.6 Easy Steam Cleaning
This allows cleaning of the dirt (not remain-
ing for a long time) that is softened by the
steam inside the oven and by the water
droplets condensed in the internal surfaces
of the oven easily.
1. Remove all accessories inside the oven.
2. Add 500 ml water into the tray and place
it on the 2nd shelf of the oven.
Do not use distilled or filtered wa-
ter. Use ready-made waters only.
Do not use flammable, alcoholic or
solid particulate solutions instead
of water.
3. Set the oven to the easy steam cleaning
operating mode and operate it for 15
minutes.
Open the door and wipe the oven interiors
with a wet sponge or cloth.
For stubborn dirt, clean the product using
dishwashing detergent, warm water and a
soft cloth or sponge and dry it with a dry
cloth.
In the easy steam cleaning func-
tion, it is expected that the added
water evaporates and condenses
on the inside of the oven and the
oven door in order to soften the
light dirt formed in your oven. Con-
densation formed on the oven door
may drip around when the oven
door is opened. As soon as you
open the oven door, wipe off the
condensation.
After the condensation inside the oven,
puddle or moisture may occur in the pool
channel under the oven. Wipe this pool
channel with a damp cloth after use and dry
it.
