Dimensions & weight
Dimensions excl. handle, incl stand (HxWxD)
[mm/inch]
1764 x 937 x 912 /
69.6 x 36.9 x 35.9
Dimensions incl. handle and stand (HxWxD)
[mm/inch]
1764 x 937 x 994 /
69.6 x 36.9 x 39.1
Shipping dimensions (HxWxD) [mm/inch]
1863 x 1000 x 1200
73.3 x 39.4 x 47.2
Net weight [kg/lbs] 292 / 644
Net weight addition for Hybrid 6-1/1 GN [kg/lbs] 9 / 20
Shipping weight [kg/lbs] 312 / 688
Clearance (left, back, right) [mm/inch] 0 x 0 x 40 / 0 x 0 x 1.6
Maximum working height [mm/inch] basic
stand
1598 / 62.9
Water requirements
Water connection [inches] 3/4
Drain [mm] Ø50
Water pressure (min-max) [bar] 1-6
Water ow [l/m] 5.5
Power requirements
Top
oven
Bottom
oven
Gas connection load [kW] 13 13
Gas connection load [BTU/H] 44400 44400
Convection thermal load [kW] 13 13
Convection thermal load [BTU/H] 44400 44400
Grid supply frequency [Hz] 60 60
Voltage 115 V 1PhN AC
Power consumption [kW] 1 1
Pre-fuse [A] 10 10
RCD model B/F B/F
Available gas types [natural/LPG] G20 / G31 G20 / G31
Gas connection size [inches] 3/4 3/4
IP classication
IP class IPX5
Heat emission
Latent heat load [kW] 0.39
Sensible heat output [kW] 1.71
Noise emission
Noise level without hood system [dB(A)] <65
Data
Wi-Fi module
IEEE 802.11 b/g/n
(2.4 GHz)
LAN RJ45
Gas
6-1/1 + 6-1/1 GN
6 400x600 EN + 6 400x600 EN
Further technical information can be found in the installation manual.
