Dimensions & weight
Dimensions excl. handle (HxWxD) [mm/
inches]
1730 x 1077 x 961 /
68.1 x 42.4 x 37.8
Dimensions incl. handle (HxWxD) [mm/
inches]
1730 x 1077 x 1043 /
68.1 x 42.4 x 41.1
Shipping dimensions (HxWxD) [mm/inches]
2050 x 1100 x 1250 /
80.7 x 43.3 x 49.2
Net weight [lbs] 720.9
Shipping weight [lbs] 765
Clearance (left, back, right) [mm/inches] 0 x 0 x 40 / 0 x 0 x 1.6
Maximum working height [mm/inches]
basic stand
1631 / 64.2
Power requirements
Power consumption [kW] 62.2
Convection output [kW] 60
Grid supply frequency [Hz] 60
Voltage 440 V 3Ph AC
Amperage [A] 89
RCD model B/F
Voltage 480 V 3Ph AC
Amperage [A] 82
RCD model B/F
Electricity
Water requirements
Water connection [inches (GHT)] 3/4
Drain [inches] Ø2
Water pressure (min-max) [psi] 15-87
Water ow [gpm] 1.5
IP classication
IP class IPX5
Heat emission
Latent heat load [kW] 4.00
Sensible heat output [kW] 3.89
Noise emission
Noise level without hood system [dB(A)] <65
Noise level with hood system [dB(A)] <65
Data
Wi-Fi module
IEEE 802.11 b/g/n
(2.4 GHz)
LAN RJ45
This appliance uses a variable frequency drive, which can be known to product high frequency electrical noise. In some cases units must be hard wired. This avoids false positives
on ground fault devices susceptible to errors from electrical noise. All installations must comply with local and national codes.
Further technical information can be found in the installation manual.
Invoq Combi 20-2/1 GN
