Block CVR-100+ MKIII handleiding
Handleiding
Je bekijkt pagina 39 van 62
39
Operating elements on the device
1. Colour display.
2. 3,5mm Headphone jack
3. USB input jack.
4. „Back“ button: press this button to return to the
previous menu item.
5. „CD Eject“ button: opens or closes the CD case.
With the first pressure of this key, the device
changes to “CD” operation mode.
6. Multifunction knob: with le / right rotation, the
volume can be raised or lowered. Press the menu
key, on the menu mode, the single points are
selected by turning and activated by pressing the
multifunction rotary knob.
7. CD-Tray
8. “Menu” button: by pressure of this key, you reach
in the system menu. A long press activates the
remote control learning function.
9. „Source“ button: by pressing this button repea-
tedly the devices will be connected in a sequence
to its sources.
10. „Play / Pause“ button: aer a simple pressure,
the device stops on pause, aer a repeated one,
it continues on replay mode. If you press it for 5
seconds, the device will be on stop mode. This
key function is valid for CD and media players.
11. „Backward“ button: press this button to return to
the previous menu item.
12. „Forward“ button: press this button on radio
mode and the device searches automatically the
next transmitter. On CD and media player mode,
the device changes to the next track.
13. “Clock” button: it changes the display to show the
time and the date. Press it again to return to the
last function.
14. „Power-Switch“ button: Pressing this button swit-
ches the device on and o (genuine mains
disconnect switch)
15. 3,5mm line in source input jack
16. Speaker output LED for A and B
17. Speaker output selection for A,B or A&B, A+B o
18. BT Headphone pairing
Connect your headphones / loudspeaker as an
output device. Select an output source (e.g. Spo
-
tify, not Bluetooth) and press the pairing button
twice. If your headphones support automatic
„handshake“, both devices will connect to each
other.
1 4 7
216 315 518 8 9 1017 11 12 13 146
