Page 5
Weather System EXA Manual Rev. E © 2019 Blizzard Lighting, LLC
2. MEET THE WEATHER SYSTEM™ EXA
MAIN FEATURES
• 8 xtures, each with 3* 15W 6-in-1 RGBAW+UV LEDs, 100,000 hours
• Independent xture swivel & tilt positioning
• Wireless rechargeable battery powered footswitch
• Built-in color macros and auto programs via DMX
• Color mixing ability in standalone mode
• Easy to use LED digital control panel
• User selectable 32-bit dimming curves
• Flicker-free constant-current 1500HZ LED driver
• Adjustable stand, dual hanging brackets, & carrying case
• 6CH/7CH/12CH/18CH/30CH/48CH or 54-channel DMX modes
• Heavy duty, black aluminum housing
• Natural convection cooled, totally silent operation
• 3-pin XLR input and output connections
• PowerCon™ compatible AC power In/Out connectors
DMX Quick Reference - 54/48/30/18-Channel Modes
54CH 48CH 30CH 18CH What it Does 54CH 48CH 30CH 18CH What it Does
1 -- 1 1 Dimmer 28 27 -- -- Blue 5
2 1 2 2 Red 1 29 28 -- -- Amber 5
3 2 3 3 Green 1 30 29 -- -- White 5
4 3 4 4 Blue 1 31 30 -- -- UV 5
5 4 5 5 Amber 1 32 31 -- -- Red 6
6 5 6 6 White 1 33 32 -- -- Green 6
7 6 7 7 UV 1 34 33 -- -- Blue 6
8 7 8 8 Red 2 35 34 -- -- Amber 6
9 8 9 9 Green 2 36 35 -- -- White 6
10 9 10 10 Blue 2 37 36 -- -- UV 6
11 10 11 11 Amber 2 38 37 -- -- Red 7
12 11 12 12 White 2 39 38 -- -- Green 7
13 12 13 13 UV 2 40 39 -- -- Blue 7
14 13 14 -- Red 3 41 40 -- -- Amber 7
15 14 15 -- Green 3 42 41 -- -- White 7
16 15 16 -- Blue 3 43 42 -- -- UV 7
17 16 17 -- Amber 3 44 43 -- -- Red 8
18 17 18 -- White 3 45 44 -- -- Green 8
19 18 19 -- UV 3 46 45 -- -- Blue 8
20 19 20 -- Red 4 47 46 -- -- Amber 8
21 20 21 -- Green 4 48 47 -- -- White 8
22 21 22 -- Blue 4 49 48 -- -- UV 8
23 22 23 -- Amber 4 50 -- 26 14 Strobe/Shutter
24 23 24 -- White 4 51 -- 27 15 Auto
25 24 25 -- UV 4 52 -- 28 16 Auto Color
26 25 -- -- Red 5 53 -- 29 17 Auto Speed
27 26 -- -- Green 5 54 -- 30 18 32-bit Dimming
DMX Quick Reference - 12/7/6-Channel Modes
CH 12-Channel Mode 7-Channel Mode 6-Channel Mode
1 Dimmer Dimmer Red Intensity
2 Red Intensity Red Intensity Green Intensity
3 Green Intensity Green Intensity Blue Intensity
4 Blue Intensity Blue Intensity Amber Intensity
5 Amber Intensity Amber Intensity White Intensity
6 White Intensity White Intensity UV Intensity
7 UV Intensity UV Intensity --
8 Strobe/Shutter -- --
9 Auto -- --
10 Auto Color -- --
11 Auto Speed -- --
12 32-bit Dimming -- --
