Page 12
UVonix™ Blackstar Manual Rev. B © 2021 Blizzard Lighting, LLC
Starting DMX Address
1.) Navigate the menu to reach DMX Address, and press <ENTER>.
2.) Use the <UP/DOWN> buttons to select a value from 001-512, and
press <ENTER> to conrm.
DMX Channel Mode
1.) Navigate the menu to reach Operate Mode, and press <ENTER>.
2.) Use the <UP/DOWN> buttons to select DMX-CH. Press <ENTER>.
3.) Use the <UP/DOWN> buttons to select CH1, CH2, or CH4, and press
<ENTER> to conrm.
M/S Mode
1.) Navigate the menu to reach Operate Mode, and press <ENTER>.
2.) Use the <UP/DOWN> buttons to select Ma./Sa. Press <ENTER>.
3.) Use the <UP/DOWN> buttons to select Master or Slave, and press
<ENTER> to conrm.
Lost DMX Signal
1.) Navigate the menu to reach Operate Mode, and press <ENTER>.
2.) Use the <UP/DOWN> buttons to select LostDMX. Press <ENTER>.
3.) Use the <UP/DOWN> buttons to select Blackout or Hold, and press
<ENTER> to conrm.
Manual Mode
1.) Navigate the menu to reach Operate Mode, and press <ENTER>.
2.) Use the <UP/DOWN> buttons to select Manual. Press <ENTER>.
3.) The Dimmer values will increase/decrease the brightness from 0% to
100%, and Strobe values will change the eect (see strobe DMX values).
Dimming Curves
1.) Navigate the menu to reach System Setting, and press <ENTER>.
2.) Use the <UP/DOWN> buttons to select DimCurve. Press <ENTER>.
3.) Use the <UP/DOWN> buttons to select Linear, Log, Exp, or
S-Curve, and press <ENTER>.
DMX% DMX% DMX% DMX%
Output
Output
Output
Output
Linear Logarithmic Exponential S-Curve
Note: Smoother (and slower) dimming capabilities can be achieved with use of the 4
available dimming curve settings.
