Page 11
Lux Reactor™ Manual - Rev. A © 2025 Blizzard Lighting, LLC
Lux Reactor™ Menu Structure
DMX Mode
Allows the unit to be controlled by any universal DMX controller.
Set the Starting DMX Address:
1.) Press the <MENU> button to reach A---.
2.) Use <UP/DOWN> to select a DMX address from 1-512.
Select the DMX Channel Mode:
1.) Press the <MENU> button to reach CH--.
2.) Use <UP/DOWN> buttons to select CH04, CH11, CH66 or CH73.
Master/Slave Mode
1.) Daisy chain the xtures via DMX in/out without a controller.
2.) Set the slave units to the same DMX address as the master xture (up to 32).
Built-in Programs
RGB LEDs
1.) Press the <MENU> button to reach C---.
2.) Use the <UP/DOWN> buttons to select a program 1-83.
3.) Press the <MENU> button to return to the main menu.
4.) The immediate main menu item will be S---, use the <UP/DOWN> buttons to
select this program speed from 0-255 (slow <-> fast).
WW LEDs
1.) Press the <MENU> button to reach A---.
2.) Use the <UP/DOWN> buttons to select a program 1-40.
3.) Press the <MENU> button to return to the main menu.
4.) The immediate main menu item will be S---, use the <UP/DOWN> buttons to
select this program speed from 0-255 (slow <-> fast).
Sound Active Mode
1.) Press the <MENU> button until you reach Soud, then press <MENU> to return
to the main menu.
A001 A001 - A512 Select starting DMX address
CH-- CH04 4-channel DMX mode
CH11 11-channel DMX mode
CH66 66-channel DMX mode
CH73 73-channel DMX mode
C --- C000 - C083 RGB color eects 0-83
S --- S000 - S255 RGB color eect speed (slow <-> fast)
A --- A000 - A040 WW eects 0-40
S --- S000 - S255 WW eect speed (slow <-> fast)
Soud Sound active mode
r --- r000 - r255 Red intensity (0% <-> 100%)
G --- G000 - G255 Green intensity (0% <-> 100%)
b --- b000 - b255 Blue intensity (0% <-> 100%)
u --- u000 - u255 WW intensity (0% <-> 100%)
t --- Current temperature (°C)
