Lux Quadra™ X4 Manual - Rev. A © 2025 Blizzard Lighting, LLC
Main Features
• Quad-cell LED blinder with strobe and aura background eects
• 4* 50W vintage warm white (amber) 1900K LEDs
• 128* 0.2W RGB LEDs for aura/background eects
• 124* 0.2W RGB LEDs for LED ring eects
• Multiple programs with adjustable speed (CW and RGB)
• Sound active modes available in standalone mode
• Variable electronic dimming
• 1–25Hz strobe eects
• 5-pin DMX input and output
• PowerCON® True1-compatible power input
Control
• Protocol: USITT DMX-512, RDM
• DMX Channels: 11/23/32 DMX channels
• Easy-to-use 4-button control panel with LED display
• Operating modes: DMX512, M/S, auto, sound active mode
2. MEET THE LUX QUADRA™ X4
DMX Quick Reference (11/23/32-Channel Modes)
11CH 23CH 32CH Function
1 1 1 Master Dimmer (0% <-> 100%)
2 -- -- Strobe (slow <-> fast)
3 -- -- WW LED 1-4 Dimmer (0% <-> 100%)
-- 2 2 WW Strobe (slow <-> fast)
-- 3-6 3-6 WW1/WW2/WW3/WW4 dimmers (0% <-> 100%), CH6 is also the
Built-In Program dimmer (CH7).
-- 7 7 Built-In Programs (see p. 12)
-- 8 8 Built-In Program Speed
Clockwise (slow <-> fast)
Counterclockwise (slow <-> fast)
-- 9 9 Aura & Ring Strobe (slow <-> fast)
4 10 -- Red Dimmer - Aura (0% <-> 100%)
5 11 -- Green Dimmer - Aura (0% <-> 100%)
6 12 -- Blue Dimmer - Aura (0% <-> 100%)
-- -- 10-12 R/G/B Aura 1 (0% <-> 100%)
-- -- 13-15 R/G/B Aura 2 (0% <-> 100%)
-- -- 16-18 R/G/B Aura 3 (0% <-> 100%)
-- -- 19-21 R/G/B Aura 4 (0% <-> 100%)
-- 13 22 Aura Eects (see p. 12)
-- 14 23 Aura Eect Speed
Clockwise (slow <-> fast)
Counterclockwise (slow <-> fast)
-- 15 24 Aura Eect Background Color
-- 16 25 Aura Eect Background Dimmer
7-9 17-19 26-28 R/G/B Ring Dimmers (0% <-> 100%)
-- 20 29 Ring Eects (see p. 12)
-- 21 30 Ring Eect Speed
Clockwise (slow <-> fast)
Counterclockwise (slow <-> fast)
-- 22 31 Ring Eect Background Color
-- 23 32 Ring Eect Background Dimmer
10 -- -- Built-In Programs (see p. 12)
11 -- -- Built-In Program Speed
Clockwise (slow <-> fast)
Counterclockwise (slow <-> fast)
