Page 11
Lux Capacitor™ Manual Rev. A © 2019 Blizzard Lighting, LLC
Control Panel Menu Structure
Address 001-512 To choose the DMX address
RunMode DMX 06CH To run in 6-channel mode
08CH To run in 8-channel mode
12CH To run in 12-channel mode
Manual Test Lamp 1 Red Background, 0-255 (0% <-> 100%)
Lamp 2 Green Background, 0-255 (0% <-> 100%)
Lamp 3 Blue Background, 0-255 (0% <-> 100%)
Lamp 4 Lamp 1, 0-255 (0% <-> 100%)
Lamp 5 Lamp 2, 0-255 (0% <-> 100%)
Lamp 6 Lamp 3, 0-255 (0% <-> 100%)
Dimmer Dimmer, 0-255 (0% <-> 100%)
Shutter 000-003
- No Function
004-007 - Dimmer
008-076 - Synchronized strobe (slow <-> fast)
077-145 - Pulse strobe (slow <-> fast)
146-215 - Random strobe (slow <-> fast)
216-255 - Dimmer
Program Program Speed 001-009 (fast <-> slow)
Program Num 001-015 (select a program 1-15)
Sound <ENTER> Sound active mode
Setting Screen Reverse YES ON, rotation of the display by 180°
NO OFF
Lamp Light Set <ENTER> 000-255 (0% <-> 100%)
Language EN English
CN Chinese
Sensitivity <ENTER> Mic sensitivity, 000-255 (0% <-> 100%)
Dimmer Mode Slow Slow dimming speed
Fast Fast dimming speed
Dimmer Curve LNR Linear dimming
SIN S-curve
I1S Square law curve
I2S Inverse square law curve
SysInfo V2.0 <ENTER> Software version information
DMX Mode
Allows the unit to be controlled by any universal DMX controller.
Select the Starting DMX Address
1.) Navigate the main menu to reach Address, press <ENTER>.
2.) Use the <UP/DOWN> buttons to choose a starting DMX address ranging from
001-512, press <ENTER> to conrm, or <MENU> to exit.
Select the Channel Mode
1.) Navigate the main menu to reach RunMode, press <ENTER>.
2.) Then use the <UP/DOWN> buttons to highlight DMX.
3.) Scroll to either 06CH, 08CH, or 12Ch and press <ENTER> to conrm.
Master/Slave Mode
1.) Daisy chain xtures together via DMX input/output connections.
2.) The rst xture in the DMX chain is the master xture, and the following units
will operate in unison with the master.
