Page 7
LB™ Par CSI User Manual Rev. A © 2017 Blizzard Lighting, LLC
3. SETUP
Fuse Replacement
CAUTION! The LB™ Par CSI utilizes a high-output switch-mode pow-
er supply with an internal fuse. Under normal operating conditions,
thefuseshouldnotrequirereplacement.Thefuseiseldreplaceable,
howeveritisanadvancedproceduresuitedtoqualiedindividuals.
Should your LB™ Par CSI fuse require replacement, please contact
Blizzard Lighting for instructions, or to return your unit for service.
Connecting Other LB™ Par CSI Fixtures
You will need a serial data link to run light shows using a DMX-512
controllerortorunshowsontwoormorexturessettosyncinmas-
ter/slave operating mode. The combined number of channels required
byallthexturesonaserialdatalinkdeterminesthenumberofx-
tures the data link can support.
Fixtures on a serial data link must be daisy chained in one single line.
Also,connectingmorethan32xturesononeserialdatalinkwithout
the use of a DMX optically-isolated splitter may result in deterioration
of the digital DMX signal. The maximum recommended cable-run dis-
tance is 500 meters (1640 ft). The maximum recommended number of
xturesonaserialdatalinkis32xtures.
Data/DMX Cabling
Tolinkxturestogetheryou’llneeddatacables.Youshouldusedata-
grade cables that can carry a high quality signal and are less prone to
electromagnetic interference.
Forinstance,Belden©9841meetsthespecicationsforEIARS-485
applications. Standard microphone cables will “probably” be OK, but
note that they cannot transmit DMX data as reliably over long distanc-
es. In any event, the cable should have the following characteristics:
2-conductor twisted pair plus a shield
Maximum capacitance between conductors – 30 pF/ft.
Maximum capacitance between conductor & shield – 55 pF/ft.
Maximum resistance of 20 ohms / 1000 ft.
Nominal impedance 100 – 140 ohms
