1. Power on the unit, press mode button repeatedly on rear panel or Bluetooth button from remote controller to enter
Bluetooth mode. The blue color LED will flare on the signal LED window which means the unit is ready to pair.
2. Enable the Bluetooth function on your device, and search the available device (please reference your device manual for
operation), then check the available Bluetooth device on the list. Select “ BP BS40” for pairing, and the blue color signal LED will
become stable after paired successful.
3. Select and play the music from your Bluetooth device, adjust the volume level properly, then the sound will come out from
the speaker.
4. In Bluetooth mode, you can do operation like previous/next track selection, play/pause, mute etc. by pressing relevant
button from remote controller.
Notices:
a. All Bluetooth devices are not guaranteed for pairing successfully due to different design and brand.
b. The best working distance of Bluetooth is within 10 meters without any obstacle in between.
c. The unit only can pair and work with one Bluetooth device in one time.
d. In case of an incoming phone call during Bluetooth playback; the music will stop temporary, and resume to playback after
end the phone call.
Bluetooth connect with TV: In case of your TV device has Bluetooth function, the Bookshelf speaker can wireless playback
with your TV as well. You have to turn on the Bluetooth function on your TV screen and searching “ BP BS40” for connection.
Please reference your TV's manual for the details.
Trouble shooting
1. The speaker cannot turn on.
a. Please check if the power connection is correct.
2. No sound output.
a. Please try to adjust the volume knob, mute button and check the play source.
b. please contact service center for support if the issue remained.
3. Sound distortion.
a. Please try to adjust and play the music at a lower volume level.
b. Check the status of treble/bass setting.
c. Please try to decrease the volume level on outsourcing player like TV etc.
4. The sound is sounding intermittently in Bluetooth mode.
a. Please try to move the Bluetooth device closer to speaker.
b. Please try to repair the speaker with Bluetooth device.
Specifications
General
Power requirements: DC IN 19V/1.65A
Power consumption (on mode): xxx Watt working mode
Standby power consumption :< 0.5 Watt
Output power RMS: 2 x 20W
Total harmonic distortion: <1% (1 kHz, 1W )
Audio input sensitivity: LINE IN 1: 550MV, LINE IN 2: 750MV
Frequency response: 45 Hz – 20 KHz; S/R:>/= 80dB
USB support music: MP3/WAV/WMA( not guarantee)
USB support device: up to 32GB max.
Unit dimensions: 155 x 248 x 175mm (W x H x D)
Inputs: 2 x RCA Line in
Speakers
Tweeter:1.25”/ 4Ω
Woofer impedance: 4”/4 Ω
Bluetooth
Bluetooth version: V5.3
Work range: approx.10 meters
Transmission frequency: 2.402~2.480GHz
Protocols: 2DP/AVCTP/AVDTP/AVRCP/GAVDP/HFP/HID/OPP/RFCOMM/SPP
A2DP/AVRCP
(Notes: the product spec may change without prior notice).
Accessories
Remote Controller x 1pcs
Remote control battery x 1 pair
Instruction Manual x 1pcs
Warranty card x 1 pcs
Audio cable (3.5mm stereo to RCA) x 1pcs
RCA to RCA single connector audio cable x 1pcs
AC/DC Power adaptor x 1pcs
6
