20
OVERVIEW
USER GUIDE
GENERAL INFORMATION
The drawers, baskets and shelves should be kept in
their current position unless otherwise specified in this
quick guide� The light system inside the refrigerator
compartment uses LEDs light, allowing a better lighting
than traditional light bulbs as well as a very low energy
consumption�
DISPOSAL
Doors and lids of the refrigeration appliance should be
removed before disposal in the landfill, to avoid children or
animals getting trapped inside�
CONTROL PANEL
1. LED Light
2. On/Stand-by
3. Freezer and refrigerator
compartment temperature
button
2.
1.
3.
ON/STAND-BY
Press the button for 3 seconds to turn the appliance
off� In Stand-by mode the light in the refrigerator
compartment does not turn on� Press the button again
briefly to reactivate the appliance�
Note: this does not disconnect the appliance from the power
supply.
FREEZER AND REFRIGERATOR
COMPARTMENT TEMPERATURE
The three LED indicators indicate the refrigerator
compartment set temperature� It is possible to set a
different temperature of the appliance with the
button�
The following adjustments are possible:
LEDs lit Set temperature
High (less cold)
Medium-high
Medium
Medium-low
Low (colder)
FAN*
The Fan improves temperature distribution inside the
refrigerator compartment, allowing better preservation of
stored food� The fan will start/stop working depending on
the temperature and/ or humidity level inside the fridge�
Note: the fan restarts automatically after a power cut or after
turning off the appliance. Do not obstruct the air intake area
with food items.
FREEZING FRESH FOOD
Place the fresh food to be frozen in the FREEZING ZONE in
the freezer compartment avoiding the direct contact with
the food that is already frozen� To optimize the freezing
speed, the lower drawer can be removed and the food can
be placed directly on the bottom of the compartment�
FAST COOL FUNCTION (FAST COOLING)
To quickly cool the refrigerator
compartment, or 6 hours before
putting a large quantity of food to be
frozen in the freezer compartment,
turn on the “Fast Cooling” function by
repeatedly pressing the
button until the 3 icons flash
green and then stay constant� The function automatically
turns off after 30 hours and the temperature returns to the
previous setting when the function is turned on�
To turn the function off manually, press the button�
Note: avoid a direct contact between the fresh food and the
food that is already frozen.
To optimize the freezing speed, the lower drawer can
be removed and the food can be placed directly on the
bottom of the compartment�
Recommended setting:
• Refrigerator compartment: MEDIUM
To avoid food waste, please refer to the recommended setting
and storage times found in the online user manual.
To avoid an increase of food waste, refer to recommended
setting and Storage Time in OPERATION chapter
