English
English
Front Panel
1. Input
Plug your guitar in here. Always use a good quality screened guitar lead.
2. Gain
The amplier can be adjusted between a clean and light overdrive response by
adjusting the Gain control. Low settings (counter clockwise) will deliver a clean sound.
As the Gain control is increased clockwise the valves will be driven harder, producing
warmer tones with more harmonics. The actual tone will be dependant on the player’s
dynamics and choice of guitar.
3. Drive Select
Press this switch to engage the built-in drive circuit taking you from a dynamic crunch
to singing, smooth legato.
NOTE: This switch must be pressed to allow the use of a compatible footswitch to
engage the Drive.
4. Tone
The Tone control allows adjustment of the balance between treble and bass
frequencies within the sound. At low settings (counter clockwise) the sound will be
warmer and darker in character. As the Tone control is rotated clockwise the sound
will become brighter.
5. Reverb
The Reverb control sets the overall level of the reverb eect. With the control fully
counter clockwise there will be no reverb. Turning the control clockwise will increase
the amount of reverb.
6. Master Volume
This controls the output volume of the amplier. Turning it clockwise increases the
volume, pushing the Class A power stage into saturation.
7. Power Indicator Light
The power indicator will light when the amplier is switched on.
8. Standby
This switch enables the operation of the speaker output. For silent recording or
practice this switch should be put in the standby position. This will disable the
speaker output, but the emulated output will continue to work.
9. Power
This switch is used to turn the amplier on and o. You should always turn this
switch on before turning on the Standby switch (8).
Rear Panel
1. Mains Fuse
The value of the Mains Fuse is specied on the rear panel. Never use a fuse of the
incorrect value or attempt to bypass it.
2. Mains Input
The supplied detachable mains lead is connected here. The lead should only
be connected to a power outlet that is compatible with the voltage, power and
frequency requirements stated on the rear panel. If in doubt get advice from a
qualied technician.
3. H.T. Fuse
The value of the H.T. Fuse is specied on the rear panel. Never use a fuse of the
incorrect value or attempt to bypass it.
4. Speaker Outputs
The output marked ‘1x16 Ohm’ is for the connection of a single 16 Ohm extension
speaker cabinet (or the internal loudspeaker of the TV-10 A combo).
The outputs marked ‘1x8 Ohm or 2x16 Ohm’ are for the connection of either a single
8 Ohm extension cabinet or two 16 Ohm cabinets. Also, the internal loudspeaker
of the TV-10 A combo can be plugged in here if it is used with a 16 Ohm extension
cabinet. See table below.
‘1x16 Ohm’ output ‘ 1x8 Ohm or 2x16 Ohm’ outputs
Internal 16 Ohm combo speaker X X
Internal 16 Ohm combo speaker X
plus one 16 Ohm extension cab
One 16 Ohm extension cabinet X X
Two 16 Ohm extension cabinets X
Single 8 Ohm extension cabinet X X
WARNING: The output marked ‘1x16 Ohm’ should never be used at the same
time as any of the outputs marked ‘1x8 Ohm or 2x16 Ohm’. Failure to correctly
match the impedance of the amplier and speakers will damage the amplier.
5. Speaker Emulated Output
This output emulates the tonal characteristics of a guitar speaker cabinet and
provides a natural valve overdrive tone for connection to a recording device or
mixing desk. Always use a good quality screened lead.
IMPORTANT NOTE: Always use a TRS/stereo jack lead when using this output,
as this will not function with a mono jack lead.
A TRS/stereo ‘Y-lead’ is provided to split the signals to mono when needed.
