Chapter 1: Specifications
1. Specifications
Data Rates 10/100/1000 and 10G Ethernet
NOTE: Switch ports are transparent to data rates, formats, and protocols.
Output Status Relay
Contact Rating
30 VDC, 1 A maximum (resistive)
Remote Contol Inputs External dry contact not to exceed 100 ohms resistance, including cable
Switching Durablility 1,000,000 operations
Switching Load Additional 80 mA DC,
Additional 20 mA (AC RMS)
NOTE: The switching load is constant in the B state, and therefore must be
added to the steady state load.
Connectors SW1046A:
A/B Switch Port: (3) DB9 F,
Ethernet Control Port: (1) RJ-45,
Serial Control PortL: (1) DB9 F,
Remote Control Status Port: (1) 6-position pluggable Phoenix terminal block
Power: (1) 2.1 x 5.5 power jack
SW1047A:
A/B Switch Port: (3) DB9 F,
Remote Control Status Port: (1) 6-position pluggable Phoenix terminal block,
Power: (1) 2.1 x 5.5 power jack
Indicators (2) Switch Position LEDs (A and B),
(1) Command Status LED
Power 100–240 VAC, 50/60-Hz wallmount power supply, 12-VDC output
Environmental Temperature Tolerance:
Operating: 32 to 104° F (0 to 40° C),
Storage: -4 to 158° F (-20 to 70° C)
Humidity Tolerance: Up to 95%, noncondensing
Altitude: Up to 10,000 ft. (3048 m)
Dimensions 2.5"H x 6.25"W x 8.1"D (6.4 x 15.9 x 20.6 cm)
Weight 4 lb. (1.8 kg), including power supply
