Page 14
Chapter 6: Ethernet Network Interface Setup
6. Ethernet Network Interface Setup (SW1046A)
To perform initial setup of the network management interface on the A/B Switch you will need a serial terminal
capable of 9600 baud, no parity, 8 data bits, and 1 stop bit. Connect this terminal to the DB9 console connector
on the A/B Switch. A straight thru M/F cable is required to connect to an IBM PC standard DB9 serial port. For
connection to other device types a custom cable pinout may be required—see Table 6-1 below for the DB9 pin
assignment on the A/B Switch.
Table 6-1. DB9 Pin Assignment.
DB9 Signal Direction
2 Received Data To Terminal
3 Transmitted
Data
From Termi-
nal
5 Ground —
Apply power to the system.
After initialization is complete you will see a sign-on message displayed on the serial console, e.g.
D1000 Network Agent Version 2.9h MAY 2008
Copyright 2008 (c)
All rights reserved
System starting …
Rack position A
Console ready
>
At this point, the A/B Switch is ready to accept the configuration commands that are necessary before you will
be able to communicate with the unit over an Ethernet network. You will need to enter an IP address, subnet
mask, and gateway address information for basic access. You will also need to set the read and write SNMP
community names if using SNMP, or a web password to allow web browser access, or a telnet password if you
plan to control the A/B Switch via telnet. After entering these parameters you will need to save them into non-
volatile memory on the A/B Switch. Any time one or more of these parameters is changed; they must be saved
followed by a system RESET in order for the changes to become permanent. The following shows a typical
setup session. Change the entered parameters to suit your application requirements. All of the console level
commands are described in detail in Section 7.
