8
1.877.877. 2269
BLACKBOX.COM
SPECIFICATIONS FOR EMERALD PE TRANSMITTER AND RECEIVER, SINGLE-HEAD
(EMD2000PE-T, EMD2000PE-T-P, EMD2000PE-R, EMD2000PE-R-P)
APPROVALS
UNIT
Directive 2014/30/EU, CE, FCC, ICES, UKCA, 2011/65/EU, 2015/863/EU, Reach, TSCA, CB
POWER SUPPLY
Directive 2014/35/EU, EN 62368-1:2014, UL, cUL, GS, PSE, BSMI, RCM, BIS, CB
PHYSICAL
LED INTERFACE
(1) Power LED (lights when power is on);
NOTE: Unit automatically powers on when plugged in; must be powered off at the power source.
(1) RJ-45 Speed LED (green, located on top left of RJ-45 connector):
Blinks three times when the network connection is 1000 Mbps,
Blinks two times when network connection is 100 Mbps,
Blinks once when the network connection is 10 Mbps,
Not blinking: No link to network;
(1) Activity LED (green, located on top right of RJ-45 connector):
Solid green: Link up,
Blinking: Activity on the link,
OFF: No link
MAXIMUM DISTANCE FROM
CPU TO TRANSMITTER
5 m (16.4 ft.), DVI-D and USB limitations
MAXIMUM DISTANCE BETWEEN
TRANSMITTER AND RECEIVER
328 ft. (100 m), use a network switch to get farther distances
OPERATING SYSTEM SUPPORT
Microsoft Windows
®
10/11, Server OS, LInux
®
, and Mac OS
CONNECTORS
EMD2000PE-T:
(1) DVI input, (1) USB Type B female, (1) RJ-45 network,
(1) SFP network, (2) 3.5-mm audio,
(1) 3-pin locking connector for power, (1) Micro USB connector;
EMD2000PE-T-P:
(1) DVI input, (1) USB Type B female, (1) RJ-45 PoE network,
(1) SFP network, (2) 3.5-mm audio,
(1) 3-pin locking connector for power, (1) Micro USB connector;
EMD2000PE-R:
(1) DVI output, (4) USB Type A female, (1) RJ-45 network,
(1) SFP network,
(2) 3.5-mm audio for SPK and MIC,
(1) 3-pin locking connector for power, (1) Micro USB connector;
EMD2000PE-R-P:
(1) DVI output, (4) USB Type A female, (1) RJ-45 PoE network,
(1) SFP network,
(2) 3.5-mm audio for SPK and MIC,
(1) 3-pin locking connector for power, (1) Micro USB connector
DIMENSIONS
1.32" H x
7.62" W x 5.79" D (34 x 194 x 147 mm)
WEIGHT
1.18 lb. (535 g)
OPERATION
DEFAULT IP ADDRESS
EMD2000PE-T, EMD2000PE-T-P: 192.168.1.22;
EMD2000PE-R, EMD2000PE-R-P: 192.168.1.21
ENCRYPTION
Secure Sockets Layer (SSL) over TCP/IP, 128-bit between transmitter and receiver, user set between receiver and virtual machine
DEFAULT USERNAME
admin
DEFAULT PASSWORD
The password is blank by default.
DDC SUPPORT
Built-in/clone of remote
POWER
POWER SOURCE
External in-line power supply or PoE IEEE 802.11af (EMD2000PE-T-P, EMD2000PE-R-P only)
INPUT VOLTAGE
100–240 VAC, 50/60 Hz
INPUT CURRENT
1 Amp maximum
POWER CONSUMPTION
Unit: 7.5 W with keyboard and mouse attached;
Power supply: 36 W to support USB-based powered devices
HEAT DISSIPATION
122.76 BTW/hr maximum
OUTPUT CONNECTOR
3-pin locking connector (12 VDC, 3 Amp output)
INPUT CONNECTOR
IEC-320, C14
POWER SUPPLY CORD LENGTH
6 ft. (1.8 m)
ENVIRONMENTAL
OPERATING TEMPERATURE
32 to 104° F (0 to 40° C)
STORAGE TEMPERATURE
-4 to +140° F (-20 to 60° C)
OPERATING HUMIDITY
5 to 95%, noncondensing
CHAPTER 1: SPECIFICATIONS
