6
1.877.877. 2269
BLACKBOX.COM
WHAT’S INCLUDED WITH THE TRANSMITTER
(E MD200DP-T)
(1) EMERALD ZEROU DISPLAYPORT TRANSMITTER
TRANSMITTER
NOTE: The EMD200DP-T cannot support USB-redirected connections.
EMERALD ZEROU DISPLAYPORT TRANSMITTER (EMD200DP-T)
SPECIFICATIONS FOR EMERALD ZEROU DISPLAYPORT TRANSMITTER (EMD200DP-T)
APPROVALS
UNIT
Directive 2014/30/EU, CE, FCC, UKCA, 2011/65/EU, 2015/863/EU, Reach, TSCA, CB
PHYSICAL
LED INTERFACE
(1) Power LED (green);
(1) RJ-45 Speed LED (green, located on top left of RJ-45 connector):
Blinks three times when the network connection is 1000 Mbps,
Blinks two times when network connection is 100 Mbps,
Blinks once when the network connection is 10 Mbps,
Not blinking: No link to network;
(1) Activity LED (green, located on top right of RJ-45 connector):
Solid green: Link up,
Blinking: Activity on the link,
OFF: No link
MAXIMUM DISTANCE FROM
CPU TO TRANSMITTER
12” (305 mm) via connected cable harness
MAXIMUM DISTANCE BETWEEN
TRANSMITTER AND RECEIVER
328 ft. (100 m), use a network switch to get farther distances
OPERATING SYSTEM SUPPORT
Microsoft Windows
®
10/11, Server OS, LInux
®
, and Mac OS
CONNECTORS
(1) DisplayPort input, (2) USB Type A female, (1) RJ-45 network (10/100/1000BASE-T),
(1) 2.5-mm barrel for power;
NOTE: The ZeroU transmitter can be powered via (2) USB Type A connectors or via an optional DC power adapter.
DIMENSIONS
0.98" H x 2.78" W x 6.12" D (25 x 71 x 155 mm)
WEIGHT
0.4 lb. (181 g)
OPERATION
DEFAULT IP ADDRESS
192.168.1.22
ENCRYPTION
Secure Sockets Layer (SSL) over TCP/IP, 128-bit between transmitter and receiver
DDC SUPPORT
Built-in/clone of remote
POWER
POWER SOURCE
Via USB or an optional 5VDC power adapter
INPUT VOLTAGE
5VDC
ENVIRONMENTAL
OPERATING TEMPERATURE
32 to 104° F (0 to 40° C)
STORAGE TEMPERATURE
-4 to +140° F (-20 to 60° C)
OPERATING HUMIDITY
5 to 95%, noncondensing
NOTE: The Emerald ZeroU DisplayPort transmitter
(EMD200DP-T) supports embedded audio on the
DisplayPort connector.
The Emerald
®
system will take audio from your
DisplayPort™ connector and transmit it across
the network just like it does with the video
signal. The receiver will decode this and send it
out the receiver’s 3.5-mm audio connector with
no configuration required in Emerald.
NOTE: The graphics card and OS must support
embedded audio over DisplayPort, and it may
need to be enabled on your system.
NEED HELP?
LEAVE THE TECH TO US
LIVE 24/7
TECHNICAL
SUPPORT
1.877.877. 2269
CHAPTER 1: SPECIFICATIONS
