14
1.877.877. 2269
BLACKBOX.COM
SPECIFICATIONS FOR EMERALD PE DISPLAYPORT TRANSMITTER, DUAL-HEAD (EMD2002PE-DP-T)
APPROVALS
UNIT
Directive 2014/30/EU, CE, FCC, UKCA, 2011/65/EU, 2015/863/EU, Reach, TSCA
POWER SUPPLY
Directive 2014/35/EU, EN 62368-1:2014, UL, cUL, GS, PSE, BSMI, RCM, BIS, CB
PHYSICAL
LED INTERFACE
(1) Power LED;
(1) Network LED;
(1) Video 1 Status LED;
(1) Video 2 Status LED;
(1) RJ-45 Speed LED (green, located on top left of RJ-45 connector):
Blinks three times when the network connection is 1000 Mbps,
Blinks two times when network connection is 100 Mbps,
Blinks once when the network connection is 10 Mbps,
Not blinking: No link to network;
(1) Activity LED (green, located on top right of RJ-45 connector):
Solid green: Link up,
Blinking: Activity on the link,
OFF: No link
MAXIMUM DISTANCE FROM
CPU TO TRANSMITTER
5 m (16.4 ft.), DisplayPort™ and USB limitations
MAXIMUM DISTANCE BETWEEN
TRANSMITTER AND RECEIVER
328 ft. (100m) CATx
Fiber: Distance dependent on SFP and Fiber cable used
OPERATING SYSTEM SUPPORT
Microsoft Windows
®
10/11, Server OS, LInux
®
, and Mac OS
CONNECTORS
EMD2002PE-DP-T: (2) DisplayPort female, (1) USB Type B female, (1) 3.5-mm audio, (1) RJ-45 Interconnect, 1Gbps, (1) SFP
Interconnect, 1 Gbps (unpopulated), (1) USB Type B micro (Console), (1) 3-pin locking connector for power
(12VDC);
EMD2002PE-DP-R: (2) DisplayPort female, (4) USB Type A female, (1) 3.5-mm audio, (1) RJ-45 Interconnect, 1Gbps, (1) SFP
Interconnect, 1 Gbps (unpopulated), (1) USB Type B micro (Console), (1) 3-pin locking connector for power (12VDC)
DIMENSIONS
1.34" H x 5.39" W x 6.1" D (34 x 137 x 155 mm)
WEIGHT
0.85 lb. (385 g)
OPERATION
DEFAULT IP ADDRESS
EMD2002PE-DP-T: 192.168.1.22;
EMD2002PE-DP-R: 192.168.1.21
ENCRYPTION
Secure Sockets Layer (SSL) over TCP/IP, 128-bit between transmitter and receiver, user set between receiver and virtual machines
DDC SUPPORT
Built-in/clone of remote
POWER
POWER SOURCE
External in-line power supply
INPUT VOLTAGE
100–240 VAC, 50/60 Hz
INPUT CURRENT
1 Amp maximum
POWER CONSUMPTION
36 W maximum (Unit consumes 9.5 W)
HEAT DISSIPATION
122.76 BTW/hr maximum
OUTPUT CONNECTOR
3-pin locking connector (12 VDC, 3 Amp output)
INPUT CONNECTOR
IEC320, C14
POWER SUPPLY CORD LENGTH
6 ft. (1.8 m)
ENVIRONMENTAL
OPERATING TEMPERATURE
32 to 104° F (0 to 40° C)
STORAGE TEMPERATURE
-4 to +140° F (-20 to 60° C)
OPERATING HUMIDITY
5 to 95%, noncondensing
CHAPTER 1: SPECIFICATIONS
