10
CONNECTIONS & CONFIGURATION
5
BASIC CONNECTIONS
Power
First off, you’ll have to decide on how you are
going to power the camera. You have three
choices. You can use PoE+ (Power over Ether-
net) or, if your network doesn’t support PoE+,
you can use the included 12VDC power adap-
tor. Lastly, you can decide to opt for the
built-in battery. If available, PoE+ is the easier
choice, since you can use the same Ethernet
cable to power and control the camera, as well
as send the video, audio and data. For the
purposes of this quick start guide, we’ll assume
your network offers PoE+ (IEEE 802.3at).
Network
Connect your camera to a network switch with
a Cat5/6 cable. By default, the camera is
configured to automatically obtain an IP
address via DHCP. Some standalone or private
networks may not have a DHCP server. After
30 seconds of waiting for an automatically
assigned IP address, your camera will fall back
to a default address of 192.168.100.100. To
ensure that you can always reach your camera,
it is recommended that you don't change this
default.
Power Up
When first powered up, the camera will per-
form its initialization routine by rotating to the
left and then centering again.
BASIC CONFIGURATION
NDI® Tools
NDI® Tools is a free suite of applications
designed to introduce you to the world of IP
video and is available at:
https://ndi.video/tools/
Once installed, launch the Studio Monitor
(Video Monitor, if using a Mac) application.
This simple application allows you to view all
NDI® sources on your network. Right click on
the Studio Monitor window to view your
camera as an NDI® source.
Tip
By default, the displayed sources have names
that include the last five digits of your camera
MAC address which is displayed on the bottom
of the camera.
Clicking on your camera in the source list will
display the image from your camera with the
default automatic settings.
