21
Pan Tilt Zoom Menu
The Pan Tilt Zoom menu is used to select the pan/tilt/zoom mode.
Digital Zoom
On: 12X digital zoom is activated. Digital zoom activates after the optical zoom reaches its maximum of 12X.
O: Only optical zoom is available.
SRZ (Super Resolution Zoom): expands zoom range to 18X zoom at 4K, or 24X zoom at FHD without sacricing
detail.
Zoom Ration OSD
Determines whether the zoom ratio displays on screen.
AF Sen
When set to NORMAL, autofocus response will be fast and suited for frequently moving subjects. When set to
LOW, the autofocus response is slowed which can improve the stability of the focus in low light conditions.
MF Speed
Choose between eight manual focus speeds.
Near Limit
You can set the camera to ignore focusing on subjects that are closer than a designated distance. Can be set in a
range from OVER, 1cm, 11cm, 30cm, 80cm, 1.2m, 1.4m, 1.6m, 2.0m, 2.5m, 3.1m, 4.2m, 6m, 10m, 20m.
Adaptive P/T
When set to ON, P/T speed are adaptive to the zoom range. For example, the higher zoom ratio you use, the slower
the speed of P/T.
P/T Speed
The P/T Speed can be set from 0 to 5 (from low to high), when controlling using the remote controller.
Preset Speed
Set the preset recall movement speed from 0 to 5.
Pan Dir
Camera horizontal Left and right orientation setting with the option to Invert.
Tilt Dir
Camera tilt up and down orientation setting with the option to Invert.
System Menu
Pelco ID
When using RS485 (PELCO P/D) control, set Camera ID to the controlled address. This value is from 001-255.
IR-Receive (Infrared Signal Reception)
When this is set to OFF, the camera does not receive the signal from the infrared remote controller. Be sure to keep
it set to ON when you use the infrared remote controller. Note that you cannot set IR-RECEIVE to OFF when you
operate the menu using the infrared remote controller. To set it to OFF, use the appropriate VISCA controller.
Display Info
When this item is set to ON, the camera conguration is displayed for approx. 3 seconds on the screen when the
camera is powered on or rebooted.
