19
Manual: You can set the bandwidth for signals undergoing contour emphasis. You can choose from DEFAULT, LOW,
MIDDLE, HIGH, and WIDE. For example, when you choose MIDDLE, the middle range of the signals is elevated, and
contours in that middle range are emphasized.
Crispening
You can choose the neness of the objects subject to contour correction with contour correction signals. Choose
a value from 0 to 7. When you choose a higher value, minute contour correction signal elements are removed, and
only the high level contour correction signals are left,which reduces noise. When you choose a lower value, minute
contour correction signal elements are added to the picture, increasing noise.
H/V Balance
You can choose the ratio for horizontal and vertical contour correction signal elements. Choose a value from –2 to
0 to +2. When you choose a higher value, the horizontal contour correction elements become greater compared
to the vertical elements.
B/W Balance
You can adjust the balance between contours in black on the low brightness side of the spectrum and contours in
white on the high brightness side. Choose from TYPE 1 to TYPE 5. The ratio of contours in black is higher for TYPE1
while the ratio of contours in white is higher for TYPE 5.
Limit
You can set the maximum value for the amount of contour emphasis in black on the low brightness side of the
spectrum and in white on the high brightness side. Choose a value from 0 to 7.
Highlight Detail
You can adjust the level of contour added to brightly lit objects. Choose a value from 0 to 4. Adjust this when you
want to emphasize the contour of a brightly lit object in a bright background.
Super Low
Emphasizes contours in the super low range. Choose a value from 0 to 7. The greater the value, the greater the
contour emphasis. Contrast and resolution increase.
Picture Menu
2D /3D NR
2D Noise Reduction is a method of reducing noise within an image by comparing the image from frame to frame,
removing variations that do not appear in each frame. 3D Noise Reduction is a method of reducing noise by
comparing variances within the same frame, as well as comparing frame to frame. This will often reduce noise
without leaving trails behind a moving object.
Flip
Flips the image upside down for ceiling mounted cameras. Select from upright mode (OFF) or ceiling mount (ON).
Mirror
Displays a mirror image of the video image.
Color
Adjusts the intensity of colours in the image from a range of 1-15.
Hue
Adjusts the color phase from 1-15.
ND lter
The ND Filter installed in front of the image sensor can be mechanically engaged or disengaged. The adjustable
range of iris and shutter speed are increased by using the ND Filter. There are 2 types of ND Filters, and by
combining them, the light quantity can be reduced. Values are 1× (Filter O), 1/4×, 1/16×, or 1/64×.
