17
Slow Shutter
When set to “On,” the slow shutter functions automatically in low light conditions. This setting is available only
when the AE mode is set to “Full Auto.” The default setting is O.
S. Shutter Limit
With certain settings, in low light conditions, the shutter speed slows and the gain is increased. This function allows
you to limit the shutter speed reduction. This helps prevent image shake when shooting a moving subject in low
light conditions.
AE Speed
This setting allows you to reduce the exposure response speed. By default, optimum exposure can be obtained
automatically within approx. 1 second. The slow AE response function allows you to lengthen this response time.
Maximum Speed (Maximum Shutter Limit)
In auto modes, the brighter the object is, the shutter speed will increase. You can set the upper limit on the shutter
speed increase, helping to make images with motion more smooth.
Minimum Speed (Minimum Shutter Limit)
In low light conditions, the shutter speed may becomes slow and the gain is increased. Here you can put a limit on
the shutter speed reduction, helping to prevent camera shake when you shootingb moving subjects.
Back Light
When the background of the subject is too bright, or when the subject is too dark due to shooting in the AE mode,
back light compensation can help make the subject better exposed.
Spot Light
Spotlight compensation will attempt to compensate exposure in conditions where strong light falls on the subject,
such as a person’s face in a spotlight. You can choose either ON or OFF. This setting is enabled when MODE is FULL
AUTO, SHUTTER PRI, IRIS PRI, or GAIN PRI. SPOT LIGHT becomes disabled when BACK LIGHT is ON.
Ex-Comp (Exposure Compensation)
When MODE is set to FULL AUTO, SHUTTER PRI or IRIS PRI, setting EX-COMP to ON allows exposure compensation
levels to be set from the following values: –10.5, –9, –7.5, –6, –4.5, –3, –1.5, 0, +1.5, +3, +4.5, +6, +7.5, +9, +10.5.
Setting the level to 0 disables exposure compensation. Level +10.5 is the brightest and –10.5 is the darkest
compensation value. When EX-COMP is set to OFF, exposure compensation is disabled.
White Balance Menu
WB Mode (White balance mode)
Select the white balance mode from the following:
Auto: This mode computes the white balance value within a range of values from 2500K to 7500K. This mode uses
color information from the entire frame and calculates according to manually set values for SPEED (white balance
speed), OFFSET and the MATRIX. This mode is the default setting.
Indoor: Sets the color temperature to 3200K. You can ne tune this setting using the MATRIX.
Outdoor: Sets the color temperature to 5800K. You can ne tune this setting using the MATRIX.
OPW (One Push White Balance): The One Push White Balance mode is a xed white balance mode that may be
automatically readjusted only at the request of the user (One Push Trigger), assuming that a white subject, in
correct lighting conditions can occupying more than 1/2 of the image. One Push White Balance data is lost when
the power is turned o. If the power is turned o, you'll need to reset One Push White Balance.
To select OPW:
1. Place a white subject (i.e., sheet of white paper) in the center of the frame.
2. Press the remote controller HOME button to activate the one-push white balance adjustment. You can ne
tune this setting using the MATRIX and OFFSET.
