Art. 84-0058
20
© 2024-10-17 Biltema Nordic Services AB
DK
Vælg sugeeffekt afhængigt af, hvad du vil støvsuge.
Lav effekt til sarte materialer så som langluvede
tæpper. Høj effekt til kortluvede gulvtæpper og gulve.
Lav effekt er standardindstilling, der er forvalgt, hver
gang støvsugeren tændes.
Mundstykker
▋
Name of each part
1. Electric floor brush 2. Floor brush release butt on
3. Conductive tube 4. Conductive tube release button
5. HEPA 6. Cyclone
7. Dust bucket 8. Dust removal button
9. Dust bucket release button 10. Main frame
11. Gear adjustment button 12. Switch button
13. Handle 14. Battery pack r elease button
15. Battery pack 16. Charging socket
17. Hanger 18. Expansion screw
19. Floor brush motor 20. Adapter
21. Long flat s uction 22. Combination suction
Gulvmundstykke: Til gulve og tæpper.
Fugemundstykke: Til trange omgivelser og hjørner.
▋
Name of each part
1. Electric floor brush 2. Floor brush release butt on
3. Conductive tube 4. Conductive tube release button
5. HEPA 6. Cyclone
7. Dust bucket 8. Dust removal button
9. Dust bucket release button 10. Main frame
11. Gear adjustment button 12. Switch button
13. Handle 14. Battery pack release button
15. Battery pack 16. Charging socket
17. Hanger 18. Expansion screw
19. Floor brush motor 20. Adapter
21. Long flat suction 22. Combination suction
Kombimundstykke: Til sofaer, møbler m.m.
Tømning
Støvsugeren er poseløs. Tøm støvsugeren ved at
åbne klappen til støvbeholderen, og hæld støvet ud.
9. PLEJE OG VEDLIGEHOLDELSE
Rengøring af fi ltret
ADVARSEL!
• Tag altid batteriet af før rengøring.
• Støvsugeren og ladeadapteren må ikke
sænkes ned i vand.
1. Batteriet løsnes ved at trykke på knappen for at
frigøre batteriet. Tag batteriet af støvsugeren.
2. Opsamleren løsnes ved at trykke på den knap, der
frigør opsamleren.
3. Tag ltret ud.
▋Cleaning and replacing parts
·Pour ash for daily use
Press the conductive tube release button, take off the host, and then press the
bottom cover release button of the dust cup to open the bottom cover to pour the
ash (recommendation: pour the ash in time after each use).
·
Dust cup cleaning
a) Press the conductive tube release button, remove the host, and then press the
dust cup release button to separate the dust cup from the motor assembly, and then
press the bottom cover release button of the dust cup to open the bottom cover to
pour dust.
b) Take out the filtered HEPA and take out the cyclone cone.
c) Filter HEPA with clean water and add a small amount of water to clean it and put it
in the container for rinsing. Be careful not to rub HEPA vigorously, so as not to
damage the structure of the filtered HEPA and affect the filtering effect. Please place
the cleaned filtered HEPA in a ventilated place and dry it before using it again. .
(Figure below)
d) The dust buc
ket, dust bucket bottom cover, and cyclone separation cone can be
directly rinsed with tap water and can be used after drying.
e) After pouring the ash, close the bottom cover of the dust cup, and then install the
dust cup and the motor assembly.
·Electric floor brush cleaning
1. Roll the left side slide button on the reverse side of the floor brush to the outside,
and lift the slide button locking blo ck. (As shown below)
2. Take out the roller brush from the slot and clean it up (not w
ashable).
3. After cleaning, assemble in the reverse order of disassembly, and reset the roller
br ush c ove r.
——Caution: After the roller brush is used for a long time, its roller bristles may be
entangled with lo ng flocs such as hair, so it needs to be cleane d in time so that the
vacuum cleaner can work more effectively.
4. Skyl ltret. OBS! Filteret må ikke genmonteres, før
det er helt tørt!
5. Sæt lteret i opsamleren igen, og sæt opsamleren
i støvsugeren.
Rengøring af børsten
1. Mundstykket løsnes fra røret ved at trykke på
knappen på røret og trække røret opad.
2. Rullen løsnes fra mundstykket ved at frigøre låsen
på undersiden af børsten.
▋
Cleaning and replaci ng parts
·Pour ash for daily use
Press the conductive tube release button, take off the host, and then press the
bottom cover release button of the dust cup to open the bottom cover to pour the
ash (recommendation: pour the ash in time after each use).
·
Dust cup cleaning
a) Press the conductive tube release button, remove the host, and then press the
dust cup release button to separate the dust cup from the motor assembly, and then
press the bottom cover release button of the dust cup to open the bottom cover to
pour dust.
b) Take out the filtered HEPA and take out the cyclone cone.
c) Filter HEPA with clean water and add a small amount of water to clean it and put it
in the container for rinsing. Be careful not to rub HEPA vigorously, so as not to
damage the structure of the filtered HEPA and affect the filtering effect. Please place
the cleaned filtered HEPA in a ventilated place and dry it before using it again. .
(Figure below)
d) The dust buc
ket, dust bucket bottom cover, and cyclone separation cone can be
directly rinsed with tap water and can be used after drying.
e) After pouring the ash, close the bottom cover of the dust cup, and then install the
dust cup and the motor assembly.
·Electric floor brush cleaning
1. Roll the left side slide button on the reverse side of the floor brush to the outside,
and lift the slide button locking block. (As shown below)
2. Take out the roller brush from the slot and clean it up (not w
ashable).
3. After cleaning, assemble in the reverse order of disassembly, and reset the roller
brush c o ve r.
——Caution: After the roller brush is used for a long time, its roller bristles may be
entangled with long flocs such as hair, so it needs to be cleaned in time so that the
vacuum cleaner can work more effectively.
3. Løft låsen og rullen af.
4. Rengør rullen. Rullen må ikke skylles i vand.
5. Monter rullen igen på samme måde, som du tog
den af.
10. ELAFFALD
Brugte elektriske og elektroniske produkter, herunder
alle typer batterier, skal indleveres til en genbrugssta-
tion. (Iht. direktiv 2012/19/EU og 2006/66/EF).
LI-ION-BATTERI
Dette produkt indeholder et litium-ion-batteri. Bat-
teriet må ikke spises, åbnes, knuses, udsættes for ild
eller udsættes for høje temperaturer.
