© 2021 DELTA T LLC Ι ALL RIGHTS RESERVED.
☑ Prepare Concrete Ceiling (if applicable)
Drill three Ø 8 mm holes in the pattern shown. The hole depth should not exceed
46mm. Remove any dust from the holes. Insert three anchor bolts into the holes.
Strike the heads of the anchor bolts with a hammer, ensuring the bolt sleeves are
fl ush with the ceiling surface. Position the mounting bracket on the anchor bolts.
Ensure all three anchor bolts are fully tightened to expand and lock the anchors.
If required by local building and safety codes, install an anchor hook for the safety
cable. Drill an Ø 8 mm hole for the anchor hook. The hole depth should not exceed
46 mm. Remove any dust from the hole, and then insert the anchor hook and fully
tighten.
Ø 8 mm
45 mm 43 mm
112 mm
46 mm max
46 mm max
