User Manual for VM Refrigerators Beverage-Air

Rev. 04/25Beverage-Air10

This is a cord-connected unit, and must be connected to its own dedicated power supply. Check the dataplate on the

machine to conrm the voltage and per the dataplate use the correct fuses or HACR circuit breakers.

Note: Do not connect to GFI / GFCI outlets. Connection to that type of outlet can result in product loss due to

unsafe cabinet temperature when GFI device trips from moisture.

Power Cord

This 120 volt model is equipped with a cord and either 5-15P

or 5-20P plug.

If the power cord becomes damaged, it must be replaced

with the identical cord.

Follow All National and Local Codes

This Unit Must Be Grounded. Do not use extension cords

and do not disable or by-pass ground prong on electrical

plug.

Initial Start Up

Plug the power cord into the proper power supply.

The cabinet will soon begin to blow warm air out of the

top area, and cool air will ow from the inside blower.

The cabinet temperature has been set at the factory at

34°F and should not be adjusted by unqualied personnel.

For any adjustment, you must contact your distributor.

Cautions

Care must be taken whenever moving or servicing the

unit. The refrigerant is contained in a sealed system, but if

released it may be ammable.

Electronic Temperature Control

The unit is provided with an electronic temperature

control which controls the operation of the unit based on

the temperature of the air entering the evaporator at the

front of the unit. In order to achieve the desired product

temperature, the electronic control is factory adjusted to turn

o the refrigeration system at 35°F and start it at 39.5°F .

When you plug the unit in, the control display will illuminate.

However, there is a start-up delay of two minutes before

the compressor(s) are energized. This delay avoids the

possibility that during a power failure, the compressors

are forced to restart before the refrigerant pressures are

equalized.

The control has been factory-adjusted with a defrosting cycle

scheduled to last 6 minutes every hour to ensure that the

evaporator performs without any ice build-up.

None of the factory-programmed electronic control

parameters can be modied unless an access code is entered

(only your distributor's technical personnel have that code).

ELECTRICAL
