User Manual for UCRF Refrigerator Freezer Beverage Air
Rev. 04/25 Beverage Air 25
CONDENSER CLEANING
Rotating fan blade can cause
personal injury.
Unplug unit from power supply
before beginning to clean
condenser
CAUTION
Keeping the condenser coil clean is critical to ecient
operation.
The condenser coil is located behind the front or rear
grille of the cabinet. It should be inspected once a month
and cleaned as required. Vacuum clean all surfaces of the
condenser. Make sure no ns are bent or damaged in the
process. If there are bent ns, carefully straighten them
so that air can ow through the coils. Failure to keep
the condenser coil clean will lead to poor performance,
excessive power consumption and compressor failure
and may result in loss of property. Failure to keep the
condenser coil clean may void the limited warranty.
1. Unplug unit from power supply.
2. Remove the Phillips head screws at the top of the
panel.
3. Once the screws have been removed the you can
lower the panel.
Please note the electrical cord will still be connected
to the panel.
4. Examine condenser surface, if dusty, brush and
vacuum the dust and lint from the surface of the
coil. Brush up and down to avoid damaging the ns.
Use care to not disturb the wires connected to the
controller.
Note: If the coil is greasy, the coil will need to be
cleaned with coil cleaner and that should be left to an
experienced technician.
5. After the condenser is clean, return the grille panel to
the unit.
6. To reinstall line up the bottom of the panel to the
bottom of the unit keeping the screw holes lined up
on the panel and on the unit
7. Reinstall the screw on the top of the front grille panel.
Note: Air lters are not recommended as they restrict
the ow of cooling air.
Remove This Panel
Remove These
Screws
Condenser Surface
