User Manual for PH Warming Cabinets Beverage-Air
Rev. 04/25 Beverage-Air 15
SEQUENCE OF OPERATIONS – ELIWELL CONTROLLER
The warmer operates based on the air temperature measured by the probe located at the return air.
ON OFF
COMPONENT OPERATION
CONTROLLER
ACTION
OPERATION
CONTROLLER
ACTION
HEATER
Heater turns on
when the air
temperature at the
probe is above the
sum of the set point
+ 4
The Heater Contact is
energized
Heater turns off
when the air
temperature at
probe is equal to
or less than the
set point
The Heater Contact is de-
energized
(RTN400 - Terminal
#10 and #11)
(RTN400 - Terminal
#10 and #11)
BLOWER
The Blower turns
on when the unit
is powered on.
The Blower is wired to
constant power
The Blower turns
off when the unit is
unplugged or put
into standby.
The Blower is wired to
constant power
(RTN400 - Terminal #4
and #5)
RTN400 - Terminal #4
and #5)
LIGHT
The light will turn on
when the down
button is
pressed (or when the
door is opened with
solid doors)
The Light Contact is
energized
The light will turn
off when the down
button is
pressed (or when the
door is closed with
solid doors)
The Light Contact is de-
energized
(RTN400 - Terminal
#13 and #14)
(RTN400 - Terminal
#13 and #14)
Condition
Heater
Blower
Lights
Cabinet Temp > Set point + 4 ON ON ON or OFF
Cabinet Temperature <= Set point - 4 OFF OFF ON or OFF
Eliwell
SEQUENCE OF OPERATIONS - ELIWELL CONTROLLER
