User Manual for HH Warming Cabinets Beverage-Air

Rev. 04/25Beverage-Air16

User Manual for VEHSA Warming Cabinets Victory

Rev. 05/22 Victory 15

Electronic Controller Alarms

Alarms are always indicated by the buzzer (if present) and the alarm icon. To switch off the buzzer, press and

release any key, the relative icon will continue to flash.

NOTE: If alarm exclusion times have been set (see AL folder in the parameters table), the alarm will not be

signaled.

Alarm

Code

Trigger

Automatic

Clearance

Outputs Comments

"AH1"

Pb1 probe HIGH Temperature

alarm

User

configured

Label AH1 displayed alternately with the actual

value read by the probe Pb1

High temperature

alarm

"AL1"

Pb1 probe LOW Temperature

alarm

User

Label AL1 displayed alternately with the actual

value read by the probe Pb1

Low temperature

alarm

"OPd" Door open for more than Always

Label OPd displayed alternately with the actual

value read by probe Pb1

Door open alarm

"E1" "E1" error Always

Blink “E1 ". lf configured: cut in alarm relay, beep

the buzzer

"PB1" sensor failure

(short or open)

"E2" "E2" error Always

Blink "E2". lf configured: cut in alarm relay, beep

the buzzer

"PB2" sensor failure

(short or open)

"E3" "E3" error Always

Blink "E3 ". lf configured: cut in alarm relay,

beep the buzzer

"PB3" sensor failure

(short or open)

"E4" "E4" error

Always

Blink "E4 ". lf configured: cut in alarm relay,

beep the buzzer

"PB4" sensor failure

(short or open)

Refrigerator with Eliwell Controlle

Beverage-Ai

Eliwell

everage-Ai

Electronic Controller Alarms

Alarms are always indicated by the buzzer (if present) and the alarm icon. To switch off the buzzer, press and

release any key, the relative icon will continue to flash.

NOTE: If alarm exclusion times have been set (see AL folder in the parameters table), the alarm will not be

signaled.

Alarm

Code

Trigger

Automatic

Clearance

Outputs Comments

"AH1"

Pb1 probe HIGH Temperature

alarm

User

configured

Label AH1 displayed alternately with the actual

value read by the probe Pb1

High temperature

alarm

"AL1"

Pb1 probe LOW Temperature

alarm

User

Label AL1 displayed alternately with the actual

value read by the probe Pb1

Low temperature

alarm

"OPd" Door open for more than Always

Label OPd displayed alternately with the actual

value read by probe Pb1

Door open alarm

"E1" "E1" error Always

Blink “E1 ". lf configured: cut in alarm relay, beep

the buzzer

"PB1" sensor failure

(short or open)

"E2" "E2" error Always

Blink "E2". lf configured: cut in alarm relay, beep

the buzzer

"PB2" sensor failure

(short or open)

"E3" "E3" error Always

Blink "E3 ". lf configured: cut in alarm relay,

beep the buzzer

"PB3" sensor failure

(short or open)

"E4" "E4" error

Always

Blink "E4 ". lf configured: cut in alarm relay,

beep the buzzer

"PB4" sensor failure

(short or open)

Refrigerator with Eliwell Controlle

Beverage-Ai

Eliwell

everage-Ai
