User Manual for GF Glass Freezers Beverage-Air
Rev. 04/25Beverage-Air10
SEQUENCE OF OPERATIONS FREEZER
The refrigerator operates based on the air temperature measured by the probe located at the return air.
ON OFF
COMPONENT OPERATION CONTROLLER ACTION OPERATION CONTROLLER ACTION
COMPRESSOR
Compressor turns
on when the air
temperature at the
probe is above the
sum of the set point
+2.5
The Compressor
Contact is energized
Compressor turns
o when the air
temperature at probe is
equal to or less than the
set point -2.5
The Compressor
Contact is de-
energized
(ERC 112 – Terminal #1)
(ERC 112 – Terminal
#1)
CONDENSER FAN
The Condenser Fan
turns on when
the Compressor is
running
The Condenser Fan
is wired directly to
the Compressor, not
through the controller
The Condenser Fan
turns o when the
Compressor is not
running
The Condenser Fan
is wired directly to
the Compressor, not
through the controller
EVAPORATOR
FAN
The Evaporator
Fan turns on when
the Compressor is
running
The Evaporator Fan
is wired to the Fan
Contact.
The Evaporator Fan
turns o when the
Compressor is not
running,
The Evaporator Fan
is wired to the Fan
Contact.
(ERC 112 - Terminal #5)
(ERC 112 - Terminal
#5)
DEFROST HEATER
The Defrost Heater
will activate
on cumulative
Compressor runtime
of 6 hours, and when
temperature drops
too low
The Defrost Heater
Contact is energized
When either the defrost
is not scheduled or the
temperature at defrost
probe has reached the
defrost termination
temperature.
The Defrost Heater
Contact is de-
energized
(ERC 112 - Terminal #6)
(ERC 112 - Terminal
#6)
Condition
Compressor
Condenser Fan
Evaporator
Fan
Defrost Heater
Defrost Drain
Cabinet Temp > Set point + 2.5 ON ON ON OFF ON
Cabinet Temperature <= Set point - 2.5 OFF OFF OFF OFF ON
Defrost OFF OFF O ON ON
