User Manual for DD Refrigerators Beverage-Air

Rev. 04/25Beverage-Air24

CAUTION

Rotating fan blade can cause

personal injury.

Unplug unit from power supply

before beginning to clean

condenser

The condenser coil is located right behind the front grille on models with end mounted condensing units, and behind the

rear grille on the DD24HC model. It should be inspected once a month and cleaned as required.

1. Remove power from the unit.

2. Vacuum clean all surfaces of the condenser.

3. Some coils will have an extreme layer of dirt, dust and grease covering the exterior. This should be removed with a

wire brush, industrial vacuum or low pressure clean water before attempting to was with coil cleaner.

4. Make sure no ns are bent or damaged in the process. If there are bent ns, carefully straighten them so that air

can ow through the coils. Failure to keep the condenser coil clean will lead to poor performance, excessive power

consumption and compressor failure and may result in loss of property. Failure to keep the condenser coil clean may

void the limited warranty.

Chemical Cleaning

1. Remove power from the unit.

2. A chemical condenser cleaning can be extremely messy so it is good practice to take the unit to a low trac area or

outside to do the cleaning whenever possible.

3. Remove cover grille.

4. Slide out condensing assembly if necessary.

5. Using the directions on the coil cleaning container, mix the cleaner and water into your sprayer.

6. Starting at the top with the tip about 6 inches away, begin spraying down the coil.

7. Spray side to side then go down to the next section of the coil. Repeat this until the coil is saturated.

8. Allow cleaner to soak into the dirty coil for a few minutes and then begin to rinse the coil.

9. Clean with a SMALL amount of water pressure. Too much pressure could cause the protective ns to fold over further

blocking air ow through the coil.

10. Repeat this process as needed.

11. Let the unit dry o for a few minutes and replace the grille cover

CONDENSER CLEANING
