14
3. Tip the device in the direction of the water drainage hole
13
so
that the water can drain.
4. Allow the device to dry for at least 24 hours.
7. CLEANING AND MAINTENANCE
Before cleaning the device, ensure that the device is disconnected
from the power supply and that there is no water left in the water
tank
4
. Regular cleaning is a prerequisite for hygienic and fault-free
operation. The device can be dismantled for cleaning easily and
without tools (see chapter “6.1 Initial use”).
• In the middle of the water tank
4
, the
device has an ultrasound membrane
12
.
Carefully clean the ultrasound membrane
12
using a cotton bud each week. De-
pending on the frequency of use, you can
also clean the ultrasound membrane
12
several times a week.
• Clean the device after every use us
-
ing a soft, slightly damp cloth, paying
particular attention to the inside of the
water tank
4
. Never use abrasive,
corrosive or solvent-based cleaning
products.
• If a layer of limescale forms in the wa
-
ter tank
4
, briefly apply a citric acid
or vinegar solution beforehand.
8. WHAT IF THERE ARE PROBLEMS?
Problem Possible cause Solution
No mist,
or very
little mist,
is coming
out of the
device.
Mains adapter
14
isnot plugged in.
Insert the mains adapter
14
into a suitable socket.
There is not enough
water in the water
tank
4
.
Fill the water tank
4
up to
the “MAX” marking.
There is too much
water in the water
tank
4
.
Pour away excess water
from the water tank
4
until it only reaches the
“MAX” marking.
Ultrasound
membrane
12
is
clogged.
Clean the ultrasound
membrane
12
as
described in chapter
“7. Cleaning and
maintenance”.
The outlet
2
is
blocked.
Check that the outlet
2
isnot blocked.
Water tank
4
is
making insucient
contact with the
device.
Clean the contacts
10
with
a dry cloth. Dust may have
accumulated there.
The water that has
been added is too
cold.
Pour in warm, but not
boiling, water.
If you cannot find a solution to your problem here, contact our Cus
-
tomer Services.
9. ACCESSORIES AND REPLACEMENT PARTS
To purchase accessories and replacement parts, please visit
www.beurer.com or contact the corresponding service address
(according to the service address list) in your country. Accessories
and replacement parts are also available from retailers.
Article Article number
Beurer by Taoasis “Vitality” aroma oil (10 ml) 681.30
10. DISPOSAL
The device can be recycled more easily if you dispose of the individ-
ual elements (ceramic, wood, plastic, electronics, cables) separately.
Always disconnect the appliance from the power supply before
dismantling.
1. Pull the cover
1
, the water tank lid
3
and the water tank
4
out of the
ceramic housing
5
.
2.
Open the three rubber feet on the ba-
se of the housing and remove them.
Unscrew the screws underneath.
3. Separate the individual components
from each other.
4. Now dispose of the cover
1
, water tank lid
3
, water tank
4
,
ceramic housing
5
, mains adapter
14
and electrical compo-
nents separately from each other.
For environmental reasons, do not dispose of the device in house-
hold waste at the end of its service life. Dispose of the device at a
suitable local collection or recycling point in your coun-
try. Observe the local regulations for material disposal.
Dispose of the device in accordance with EC Directive
Waste Electrical and Electronic Equipment (WEEE). If you
have any questions, please contact the local authorities
responsible for waste disposal. You can obtain the loca
-
tion of collection points for old devices from the local or municipal
authorities, local waste disposal companies or your retailer, for ex-
ample.
11. TECHNICAL SPECIFICATIONS
Product name
LA 45 Green Planet
Power supply
Input: 100-240 V ~ 50 / 60 Hz 0.35 A
Output: 24.0 V
0.5 A; 12.0 W
Water tank capacity
140 ml
Room size
up to approx. 20 m²
Operating principle
Ultrasonic atomiser
Mist settings
Continuous mist and intermittent mist
Running time Approx. 4 hours of continuous mist
Approx. 8 hours of intermittent mist
Weight Approx. 855 g
Dimensions
Approx. 13 x 13 x 18.3 cm
Average eciency during
operation
85.63 %
Eciency at low load (10%)
79.48 %
No-load power consumption
0.069 W
Mains adapter Manufacturer:
KPTEC Guandong Quanjin Electro
-
nics Technology Co. Ltd
EU (110.183): K12E240050G,
UK: K12E240050B
12. GUARANTEE
Further information on the guarantee and guarantee conditions can
be found in the guarantee leaflet supplied.
Subject to errors and changes
