34
For pain relief treatment (TENS) using the Digital TENS/EMS device
and its 4 separately adjustable channels and 2 electrodes each, it is
advisable either to position the electrodes of a channel so that the area
aected by pain is between the electrodes or to position one electrode
directly on the area aected by the pain and the other electrode at a
minimum distance of 2 – 3 cm. You may use the electrodes of the sec-
ond channel to simultaneously treat additional areas aected by pain
or use them in conjunction with the electrodes of the first channel to
restrict the area aected by pain (position electrodes opposite). In this
case, we again recommend positioning electrodes in a cross arrange-
ment.
Tip for the Massage function: always use at least 4 electrodes for op-
timum treatment.
Use the electrodes on skin that is clean and preferably free from hair
and grease in order to prolong the life of the electrodes. If required,
clean the skin with water and remove hair prior to treatment.
If an electrode comes loose during use, the pulse intensity of the cor-
responding channel is reduced to the lowest level. Apply the electrode
again and reset your preferred pulse intensity.
11. CUSTOMISABLE PROGRAMS
(Applies to TENS 13-15, EMS 33-35)
The TENS 13-15 and EMS 33-35 programs can be set individually according
to your needs.
TENS 13 program
TENS 13 is a program that you can also customise. In this program, you can set
the pulse frequency to between 1 and 150 Hz and the pulse width to between
80 and 250 µs.
1.
Position the electrodes on the desired area for treatment (for positioning
suggestions, see “Information on electrode positioning” section) and con-
nect them to the device.
2.
Select the TENS 13 program as described in the “Starting use” section (step
3 to step 5).
3. Use the
/ adjustment buttons to select your preferred pulse frequency
and press the ENTER button to confirm.
4. Use the
/ adjustment buttons to select your preferred pulse width and
press the ENTER button to confirm.
5.
Use the / adjustment buttons to select your preferred treatment time
and press the ENTER button to confirm.
6. Use the
/ adjustment buttons as relevant in each case for / /
Ch3
and
Ch4
to select your preferred pulse intensity.
TENS 14 program
The TENS 14 program is a burst program that you can also customise. Various
pulse sequences run in this program. Burst programs are suitable for all areas
of application to be treated with changing signal patterns (to minimise the level
of becoming accustomed to the treatment). In this program you can set a pulse
width between 80 and 250 µs.
1.
Position the electrodes on your preferred treatment area (for positioning
suggestions, see the “Electrode positioning” section) and connect them
to the device.
2.
Select the TENS 14 program as described in the “Starting use” section (step
3 to step 5).
3. Use the
/ adjustment buttons to select your preferred pulse width and
press the ENTER button to confirm.
4.
Use the / adjustment buttons to select your preferred treatment time
and press the ENTER button to confirm.
5. Use the
/ adjustment buttons as relevant in each case for / /
Ch3
and
Ch4
to select your preferred pulse intensity.
TENS 15 program
TENS 15 is a program that you can also customise. In this program, you can
set the pulse frequency to between 1 and 150 Hz. The pulse width changes
automatically during the stimulation treatment.
1.
Position the electrodes on your preferred treatment area (for positioning
suggestions, see the “Electrode positioning” section) and connect them
to the device.
2.
Select the TENS 15 program as described in the “Starting use” section
(step3 to step 5).
3. Use the / adjustment buttons to select your preferred pulse frequency
and press the ENTER button to confirm.
