12

STEP

1

Be careful to assemble all components

in the sequence they are presented.

NOTE:

Wrench tighten ALL hardware at the end of STEP 1B. Some components may be

pre-assembled. Nylon lock nuts will not fully screw onto bolts, they must be wrench

tighten to fully go on.

1A. Unfold the Main Frame (#17) as shown in the STEP 1 Drawing.

1B. Attach the Middle Crossmember to the Main Frame using:

(#5) M8X35mm Button Head Cap Screw, QTY: 1

(#7) M8 Nylon Lock Nut, QTY: 1

(#12) M8 Flat Washer, QTY: 1

1C. Insert the Ball Head Pop Pin (#6) into the Rear Frame (#20).
