10
Configuration
of power
management
Power supply
per phase [A]
Number of
phases
Voltage [V]
Power limit
per phase
1
29,13 A
1
230 V
6700 W
2
13,00 A
2
230 V
3000 W
3
26,00 A
1
230 V
6000 W
4
23,91 A
1
230 V
5500 W
5
10,43 A
2
230 V
2400 W
6
18,26 A
1
230 V
4200 W
7
16,00 A
1
230 V
3700 W
8
10,43 A
1
230 V
2400 W
9
5,22 A
1
230 V
1200 W
Child lock
For activate or deactivate the child lock, it is the same process for both:
Turn the two left knobs simultaneously to the left overwind ( position “A”) and hold them for at least 3
sec.
HOB
ATTENTION:
Metal items such as cutlery or lids must never be placed on the surface of the hob since they may become
hot.
Cooking zones The appliance is equipped with 4/5 cooking zones having different diameters and
powers. Their positions are clearly marked by rings, while the heating power is only
released in the area shown on the ceramic hob. The 4/5 cooking zones are of HIGH-
LlGHT type and start to heat up a few seconds after they are switched on. The heat
level of each zone can be regulated from the minimum to the maximum setting using
the knobs on the front panel.
Underneath each cooking zone there is a coil called an inductor, supplied with power
by an electronic system, which generates a variable magnetic field. When a pan is
placed inside this magnetic field, the highfrequency currents concentrate directly on
the bottom of the pan and produce the heat needed to cook the foods.
The 4/5 lights between the cooking zones come on when the temperature of one or
more cooking zones exceeds 60° C.. The lights go out when the temperature drops
to below about 60° C.
Zone number:
Power absorption
Normal operation:
With power function:
Front left
1600 W
1850 W
Rear left
2100 W
3000 W
Central
2300 W
3000 W
Rear right
2100 W
3000 W
Front right
1600 W
1850 W
