USE
USER MENU
The user menu allows you to customise some basic
settings of the induction hob.
Press the settings icon to access the menu.
FUNCTIONS
• CUSTOMISATION: allows you to remove one of the
functions (timer, pause, key lock) from the functions
menu. The function can be added at any time
The function can be added at any time by accessing the
same menu CHILD SAFETY locks the hob so that it
cannot be activated accidentally by children.
To temporarily unlock the hob for cooking, follow the
instructions on the hob. To cancel the function, follow the
same procedure as for activation.
• SOUND: allows you to set the volume of the end-of-
cooking alarms and the pressure feedback icons. Error
signals will always be kept at maximum volume.
• BRIGHTNESS: allows you to set the brightness of the
display.
• CLOCK: allows you to set the time display format (12 h
or 24 h) and the time (using the wheels).
• LANGUAGE: allows you to choose the language for the
messages.
The available languages are English (default language),
French, Spanish, Italian, Chinese (simplified), Korean,
and Vietnamese.
• RETURN TO FACTORY SETTINGS: allows you to
return the hob settings to their original settings after
each change. You can save the new settings using the
icon at bottom right or cancel them.
SERVICE MENU
NOTE
The service menu should only be used by
the installer or specialised personnel.
To enter the service menu, the hob must be switched off
and powered for less than 2 minutes, the automatic start
test must have been completed and the display must be off
1) press the icon 3 times for a maximum of 1 second
2) press and hold the icon for 4 seconds.
• FUNCTIONS
• System information
• Induction calibration
• Display calibration
• Display function test
• Configuration
• Demo mode
• Power limitation
To exit and save the changes made, press the
confirmation button at bottom right.
• CONFIGURATION
Allows you to choose from 4 preset installation
configurations
• 0 - Factory configuration (single-phase or three-
phase connection possible)
• 2 - Power limitation for two-phase connection - 3 kW
per phase
• 3 - Power limitation for two-phase connection - 2.4
kW per phase
• DEMO MODE
Allows you to select DEMO mode for showrooms. In this
configuration, the display works but the hob does not
consume power and does not heat up.
• POWER LIMITATION
In the case of configuration 0 and single-phase
connection, it allows the power consumption to be set in
steps of 100 W.
61
