The up-stand is packed separate and is taped to the back of the cooker. Other
components can be found inside the ovens. All packaging and covering films must
be removed before the installation can commence.
All electric cookers should be installed by a qualified electrician in accordance with
IEE r
egulations and local electricity provider rules. Building regulations must be
considered when undertaking any installation. Failure to install the appliance
correctly will render the warranty null and void.
Range cookers are heavy and should be handled by two people. Never lift or drag a
range by the oven handles as damage may occur.
Note: Pictures and graphics in this manual cover different models and may vary in
minor details from your cooker.
INSTALLING RANGE COOKER
Rating of Services The rating plate is visible in the storage area of the cooker and a copy is also
attached to last page of the user manual.
Before connecting the cooker, check that the requirements on the rating plate
correspond with those of the electrical system and gas supply (where applicable).
Ensure that the electrical system and isolating switches have a suitable capacity to
carry the maximum power as indicated on the rating plate.This chart can be used as
a guide to the electrical supply ratings.
Table N°1
Cooker model Type
MCB size for
dedicated
cooker circuit
Fuse rates The cable of alimentation
60 cm single oven Gas hob top 13 AMP MCB
13 AMP FUSE
H05RR-F or H05VV-F
3X1,5
mm²
*60 cm single oven Induction hob top 32 AMP MCB
32 AMP FUSE
H07RN-F 3X4
mm²
60 cm single gas oven Gas hob top 13 AMP MCB
13 AMP FUSE
H05RR-F or H05VV-F
3X1,5
mm²
90 cm single hybrid
oven Gas hob top 16 AMP MCB
16 AMP FUSE
H05RR-F or H05VV-F
3X1,5
mm²
90 cm single gas oven Gas hob top 13 AMP MCB
13 AMP FUSE
H05RR-F or H05VV-F
3X1,5
mm²
90 cm single oven Gas hob top 16 AMP MCB
16 AMP FUSE
H05RR-F or H05VV-F
3X1,5
mm²
*90 cm single oven Induction hob top 32/40 AMP MCB
32/40 AMP FUSE
H07RN-F 3X4
mm²
90 cm twin oven Gas hob top 20 AMP MCB
20 AMP FUSE
H05BB-F or H05SS-F
3X2,5
mm²
*90 cm twin oven Induction hob top 32/40 AMP MCB
32/40 AMP FUSE
H07RN-F 3X4
mm²
100 cm twin oven Gas hob top 20 AMP MCB
20 AMP FUSE
H05BB-F or H05SS-F
3X2,5
mm²
*100 cm twin oven Induction hob top 32/40 AMP MCB
32/40 AMP FUSE
H07RN-F 3X4
mm²
100 cm XG (3 oven
compartments) Gas hob top 32 AMP MCB 30 AMP FUSE
H07RN-F 3X4
mm²
*100 cm XG (3 oven
compartments) Induction hob top 40 AMP MCB 40 AMP FUSE
H07RN-F 3X6
mm²
120cm twin oven Gas hob top + griddle 32 AMP MCB
30 AMP FUSE
H07RN-F 3X4
mm²
* With diversity factor applied
Pos
itioning The cooker may be installed in a kitchen or open-plan kitchen diner but not in a
room containing a bath or shower. The cooker should be positioned in an area with
good light and free from draughts.
