PLEASE NOTE:

When changing the sewing direction, raise the needle and

turn the fabric.

When you select stitch patterns not for twin needle sewing

and press the twin needle button, the twin needle mark will

blink on the LCD display and the caution buzzer sound.

Stitch patterns cannot be memorized in the twin needle

mode.

Use the thread cutter on the head cover when trimming

threads.

Use thin threads #60 or larger number for the twin needle

sewing.

• Starting to sew

Use the second spool pin for twin needle sewing.

Place two spools of thread as shown.

Draw both threads from the spools and thread them through the

points from to .

Make sure that the two strands of thread do not get tangled.

Turn the power switch on and select the desired pattern.

Press the twin needle button , draw the both threads to the

back or left under the presser foot.

Twin Needle Sewing

Stitch pattern: Mode 3 : 54 (Example)

Thread tension: 3 - 6

Presser foot: Satin stitch foot

Open toe foot: F2

PLEASE NOTE:

When you sew patterns with the twin needle, test the

stitches before you begin to sew.

Use Zigzag foot or Satin stitch foot for twin needle sewing.

Turn off the machine before changing the needle.

Replace the twin needle with a single needle when twin

needle sewing is ﬁnished.

MODE 1, 2

Mode 3

Stitch Patterns for Twin Needle Sewing
