Product information

6006910_0 – 18.11.2023

2.3 Product overview

H

I

A

C

B

D

F

E

G

A Chimney

B Hood body

C Upper section with bulging edge (removable)

D Lower section (removable)

E Capillar Trap (removable) - behind the lower section

F Front panel made of glass

G Control panel

H Hob lighting

I Type plate - on the inside of the front panel

A

C

D

B

A Guide aid for installing the recirculated air filter

B Connector for the mains cable

C Adjusting screws for alignment

D Fan outlet with grille

2.4 Scope of delivery

B

C

G

F

H

A

D

E

A Hood body with front panel

B Chimney (two-part, can be pulled apart)

C Chimney fastening

D Recirculated air filter BUF 150 +

E Mains cable with plug and cold device plug

F 6 nylon wall plugs 8 mm

G 6 Torx screws TX30 with integrated washers

H Operating and installation instructions

The fastening materials are only suitable for solid walls.

Further accessories may be required depending on the

operating mode.
