USE OF THE ELECTRIC GRILL
Accessories
The accessories can be inserted in the oven in 4 different shelf
positions.
You can pull the accessories two-thirds of the way out without
them tipping. This allows meals to be removed easily.
You can buy accessories from the after-sales service or from
specialist retailers.
Baking and roasting shelf
For ovenware, cake tins,
roasts, grilling and frozen
meals.
Enamelled baking tray
For moist cakes, pastries,
frozen meals and large
roasts. Can also be
inserted underneath the
wire rack or rotary spit and
used as a drip tray to
collect fat.
Rotary spit
For roasts and large pieces
of poultry. Use only in
combination with the
enamelled baking tray.
Accessory Description
1
2
3
4
Bump
Install shelves by locating them in the horizontal guide rails on
the oven walls. The raised portion of the shelf is to be facing
the rear wall of the oven.
USING THE GRILL
Turn the oven knob to the right and place it on the grill
position. The grill pan should be located on the top oven shelf
position. Always preheat the grill on full for 3-5 minutes before
inserting the food.
The user can change the shelves, depending on his personal
whishes and on the different food.
To remove the shelves from the oven, pull them forward
you, tilt front end upward and pull them out.
To replace it in the opposite manner as before.
As shown in the picture, on-off control is used to control
heating components of oven, the left is power source which
can be connected under the 220V.
1Time Adjustment after Starting up
When the power is on, it shows 12:00 and flashes. The relay
contact is disconnected, auto-programming icon keeps
lighting up, time setting icon flashes.
Press K1 or K3 to the time or press K2 to get into the present
working mode. The relay contact is connected.
Press K2 by 4 times to get into the present time-setting mode
under the common mode.
2Alarm and Buzz Function
Press K2 once under the common mode: "Alarm Icon"
flashes.”
Press K1 or K3 to adjust the present alarm clock.
5s after adjusting to the time you need, "Alarm Icon" keeps
flashing, and will work after setting up. In this case, pressing
K1 can know the alarming time( it will show seconds at one
ast minute).
When alarm counts down to zero, alarming program ends,
alarm icon flashes, and the buzzer os buzzing. Press any key
to stop the buzzing or it will turn off automatically after 2
minutes.
3 Auto-programming Setting and Instructions
Semiautomatic program mode
Use this setting for oven working time, automatic heating
switch-off at the end of setting time, buzzer will inform the
user.
Press K2 twice or three times to get into the auto-program-
ming time setting, “Auto-programming Icon” flashes. Press
K1 and K3 to aujust continuous time and end time.
5s after setting, it will work automatically, "Auto-program-
ming Icon" keeps lighting up. If continuous time is 0, turn
off the relay contact, and "Relay Operation Icon" is dark,
"Autoprogramming Icon" flashes, the buzzer is buzzing.
This mode’s range of continuous time and end time:
Adjustment range for continuous time: >0 but <10 hours
Adjustment range for end time: present time< end time < =
present time + 10 hours.
If meet this standard: end time = present time + continuous
time.
For example: the present time is 2: 00, then the max. end time
is adjusted to 12:00 (2: 0010001200). When the end time is
adjusted to 12:00, then the continuous time is 10:00.
5s after adjusted, automatic program is working.
After 10 hours, if continuous time is counting down to 0, turn
off the relay contact, and “Relay Operation Icon” is dark,
“Auto-programming Icon” flashes, the buzzer is buzzing.
Note:
1. only use this setting for either continuous time or end time.
For example: the present time is 2:00, and if let the oven
work for 3 hours, set the continuous time to 3:00, and the
end time will automatically change to 5:00 and vice versa.
2. If the continuous time is equal to 0 or the end time is equal
to the present time, it means that the automatic program is
over.
3. When the automatic program is over, the continuous time is
0 and the end time is equal to the present time.
Automatic Mode
Use this mode for setting oven’s starting time and end time,
which means make an appointment to boot. When the time is
For Warranty and technical queries: 1300 373 199 Aust OR 0508123108 NZ www.belliniappliances.com.au
14
GSM Retail Australia Pty Ltd ABN: 53 007 582 475
Using the rotary spit
The rotary spit can be used to cook joints such as rolled joints
and poultry with excellent results. The meat is roasted
thoroughly and evenly.
Use the rotary spit in conjunction with the grill.
Preparing joints
Place the joint as centrally as possible on the rotary spit and
secure it at both ends with the retaining clips.
You can also truss the joint with string. With poultry, bind the
ends of the wings underneath the back and the thighs against
the body. This will prevent them from becoming too dark.
Pierce the skin on the underside of the wings to allow the fat to
escape.
Inserting the rotary spit
Insert the rotary spit as follows:
1. Hook the spit holder into the bracket on the ceiling of the
cooking compartment.
If you require to preheat the oven, hook in the holder
before preheating.
Risk of burns
Never touch the hot surfaces of the cooking compartment
or the heating elements.
Children must be kept at a safe distance from the applian-
ce at all times.
Open the appliance door carefully. Hot steam may
escape.
2. If the oven has been preheated, only attach the rotary spit
if you are using an oven cloth or wearing (thermal) oven
gloves. To attach the spit, slide one end into the recessed
adapter in the left-hand side panel of the cooking
compartment.
Model: BFOG668X/BFOG668X-F 90cm Freestanding Oven
